The AWWA Exhibitor Preview

May 1, 2001
The Pow-R-Drive portable hand-held valve operator from E.H. Wachs can turn valves from 4" to 60" and comes in hydraulic, electric or pneumatic powered models.

Valve operator

Click here to enlarge image

The Pow-R-Drive portable hand-held valve operator from E.H. Wachs can turn valves from 4" to 60" and comes in hydraulic, electric or pneumatic powered models. The valve operator offers the performance needed for daily valve maintenance or to operate stubborn, hard-to-turn valves. The Pow-R-Arm supports the operator, taking away the need to balance or lift during setup and operation. It mounts in any standard 2" hitch and the arm provides a full 180° of swing and 18" of telescoping movement for lining up to the valve.

The E.H. Wachs Co.
Wheeling, IL
Web: www.waschsco.com

Level monitor

Click here to enlarge image

The SOLO® 1000 Digital Indicator from Force Flow/Flowquip provides a simple and accurate way to monitor chemical usage and remaining chemicals. The indicator features an LCD display, standard 4-20 mA output for remote monitoring and is housed in a NEMA 4X enclosure. The indicator is available as single- or dual-channel units that allow monitoring one or two scales or ultrasonic sensors. Optional level alarm relays make it possible to alarm low or high chemical level conditions. Start-up and operation requires initially turning a single tare/zero adjust knob.

Force Flow
Concord, CA
Web: www.forceflow.com

High-velocities magmeter

Click here to enlarge image

Marsh-McBirney recently introduced the Multi-MagT magmeter, an addition to its existing Multi-Mag product line. The new insertable multi-electrode sensor is ideal for pipe sizes 36" - 120". An array of electromagnetic sensors are strategically located on the insertable probe that spans the entire pipe diameter. The sensors detect and compensate for shifting profiles. The streamlined sensor shape minimizes flow disturbances, thus providing minimal pressure drop. The meter has proven itself in difficult flow conditions such as shifting profiles, low flows, wide flow ranges, and bend/elbow installations. The meter offers accuracies better than 1% of reading and comes with a standard five-year warranty.

Marsh-McBirney
Frederick, MD
Web: www.marsh-mcbirney.com

Tablet chlorination system

PPG's Accu-Tab System consists of 3" calcium hypochlorite tablets with 65% available chlorine used in the patented erosion chlorinator. The chlorinators have no moving parts and no small openings to clog - eliminating the need for metering pumps. A portion of the process water, whether potable or wastewater, is diverted through the chlorinator. The water flow erodes the tablet, with the amount of chlorination being controlled by the inlet water flow. The chlorinated water is then returned and mixed in with the process stream. This system is an alternative to chlorine gas cylinders and sodium hypochlorite for sanitizing water systems.

PPG Industries Inc.
Pittsburgh, PA

DOC removal

Click here to enlarge image

A new NSF-approved continuous magnetic ion exchange process from Orica Watercare is designed to remove dissolved organic carbon (DOC) from drinking water. The new system uses the patented high capacity MIEX® resin. It removes DOC at the front end of a water treatment plant in a stirred contactor, much like a flash mixer in a conventional water treatment plant. The significantly smaller resin beads provide maximum surface area and allow rapid DOC adsorption kinetics. A magnetic component is dispersed within the resin particle structure so that, when passed to a settler, the fine resin beads rapidly agglomerate into larger, fast-settling particles.

Orica Watercare Inc.
Englewood, CO

Compact ozone generators

Click here to enlarge image

Ozonia North America manufactures ozone generators capable of producing from one pound to thousands of pounds of ozone per day using high endurance non-glass dielectrics. The proprietary Advanced Technology (AT) dielectric makes it possible to produce higher concentrations of ozone than conventional generators, while using less oxygen and electricity. The new Ozonia OZAT series of ozone generators are compact and prepackaged and consume up to 50% less oxygen to generate the same amount of ozone as conventional plants.

Ozonia North America Inc.
Elmwood Park, NJ
Web: www.ozonia.com

Monitors/controllers

Click here to enlarge image
Myron L offers a variety of hand-held instruments and in-line monitor/controllers. Its new 750II series conductivity and resistivity monitor/controllers can be used as a stand-alone system or interface with a SCADA system. The company's UltrameterTM is a microprocessor based hand-held instrument that can measure six water quality parameters and deliver a measured accuracy of ±1% of reading.

Myron L Co.
Carlsbad, CA
Web: www.myronl.com

Microfiltration system

Click here to enlarge image
AriaTM Membrane Microfiltration systems are designed for drinking water filtration in municipalities with populations of 10,000 or less. The systems are skid-mounted, fully automated and self-contained to facilitate installation. Once programmed, the system will run unattended at a constant clean water production rate. The systems use Pall MicrozaTM microfiltration modules to provide drinking water purified to levels exceeding EPA's Surface Water Treatment Rule requirements. The system is capable of removing iron and manganese from groundwater sources, and turbidity, organics, color, pathogenic cysts, oocysts and viruses from surface waters.

Pall Corp.
East Hills, NY
Web: www.pall.com

Submersible level transducers

Click here to enlarge image
All-titanium small bore submersible level transducers are now available from KPSITM Transducers of Pressure Systems. This alternative complements the company's 316 stainless-steel version of small bore transducers and is ideal for marine applications in saltwater or other brackish conditions, as well as for other water/wastewater applications that require a small bore (0.74" diameter), corrosion-resistant transducer. The Model 320T transducers are accurate to + 0.25%, while Model 330T transducers offer accuracy to + 0.1%. Available level ranges are 0-4 through 0-700' of water with analog outputs of 4-20 mA, voltage, or millivolt. All KPSI submersible level transducers are certified to FM, UL, and CSA.

Pressure Systems, Inc.
Hampton, VA
Web: www.PressureSystems.com

Automatic control valves

Click here to enlarge image

OCV offers diaphragm actuated, pilot operated automatic control valves. Standard features include epoxy coatings, Y-strainers and isolation ball valves on every control circuit. Valves are available for pressure reducing, pump control, electrical and computer interfacing, altitude and float level control, pressure relief, surge anticipation and zone control. Ordering information for the ValveMaster Sizing and Selection software is offered at the company's web site at www.controlvalves.com.

OCV Control Valves
Tulsa, OK

UV disinfection

Click here to enlarge image
MegatronTM ultraviolet water disinfection systems from Atlantic Ultraviolet Corp. are multi-lamp pressure vessel chambers manufactured in Type 304 or Type 316 stainless steel. This line is particularly suited to large scale disinfection of water and wastewater. Flow rates range from 90 to 1,800 gpm. Standard features include individual lamp operational indicators, electronic ballasts, and view ports as well as drain and test ports. The modular design allows for versatile layout. Optional features include manual or automatic programmable wiping mechanisms as well as ultraviolet monitoring devices. Systems can be custom designed using lap joint flanges, sanitary fittings and special chamber coatings.

Atlantic Ultraviolet Corporation
Hauppauge, New York
Web: www.ultraviolet.com

Research foundation

The non-profit American Water Works Association Research Foundation (AwwaRF) is dedicated to "advancing the science of water." AwwaRF is the leading drinking water research organization in the world. It provides leadership to the drinking water community, and helps those involved in providing and regulating water meet the needs of the millions of people who rely on dependable access to safe drinking water. At the AWWA Annual Conference, AwwaRF will exhibit research reports available from the over $190 million in research done to date, and provide information about research in progress.

AwwaRF
Denver, CO

Dehumidifiers

Click here to enlarge image

HI-E Dry dehumidifiers from Therma-Stor Products can reduce the dew point of air in water treatment plants below the water temperature. This eliminates condensation and the resulting corrosion on pipes, filter tanks and building surfaces. The units plug into a standard 115-volt outlet and remove 5-7 pints of water per kilowatt. The Model 195 can remove more than 190 pints of water per day. The Model 100 has a smaller capacity ideal for pump houses and other smaller areas.

Therma-Stor Products
Madison, WI

Fire hydrant meter

Click here to enlarge image

Performance Meter's Model CAFHM AWWA C701 Class II Turbine Fire Hydrant Meter is offered with a locking handle that accepts all standard padlocks, including the Barrel Lock. The meters also feature reduced pressure backflow preventers.

Performance Meter Inc.
Beaumont, CA
Web: www.hpmeters.com

Hole cutter

Click here to enlarge image

Wheeler-Rex offers a second generation hole-cutter for making non-pressure taps into sewer and drain pipes. With its modular design, set-up and cutting can be done by one person. The cutters are available with a variety of power sources: gasoline engine, air, electric or hydraulic motor. All power sources mount to the same basic cutting base. The standard units will cut 4-8" holes into 6-20" diameter pipes of clay, ductile and cast iron, PVC and reinforced concrete. Taps made into larger diameters can be done with a simple extension of the binder chain. Cutters for holes up to 12" diameter are available upon request.

Wheeler-Rex
Ashtabula, OH
Web: www.wheelerrex.com

Residual monitoring

Click here to enlarge image

Chlorine dioxide offers a powerful alternative to chlorine for pre-filtration oxidation or for taste and odor control. ProMinent Fluid Controls now offers the Dulcometer D1C, specifically for continuous measurement of chlorine dioxide residual in drinking water. The equipment includes amperometric sensor technology and a microprocessor-controlled, menu-driven analyzer.

ProMinent Fluid Controls
Pittsburgh, PA

Laboratory spectrometer

Click here to enlarge image

The Odyssey laboratory spectrometer from Hach includes such advanced features as automatic wavelength selection, a touch screen display with a simple user interface, easy computer connections, and advanced software. The instrument also can read pH with an optional electrode. A newly designed cell holder allows the user to use many different sizes of sample vials without having multiple adapters. The instrument comes with all Hach chemistry calibrations built in, including the new TOC test.

Hach Company
Loveland, CO
Web: www.hach.com

Water services

Click here to enlarge image

The Integrated Groundwater Services Group of Layne Christensen Company offers turnkey water supply and treatment services for municipal utility and private industrial customers including: Pilot testing and process design; water treatment equipment design and manufacturing; turnkey construction services for water supply and treatment products; Ranney® collector wells and surface water intakes; well and pump maintenance and repair; hydrogeological services including well siting and source development; and project financing.

Layne Christensen Company
Bridgewater, NJ
Web: www.laynechristensen.com

Distribution modeling

Click here to enlarge image

Water Distribution Modeling is the first in a series of textbooks from Haestad Press® that is intended for use by both students and professionals. The book provides fundamentals, tips, modeling tricks and tools for the novice or experienced modeler. It bridges the gap between hydraulic theory and applications in the real world. Topics covered follow the model development process and contain information needed to build a water model to help identify and solve common distribution system problems. The 400-page book includes a complete version of WaterCad® on CD along with more than 100 problems that can be completed for continuing education units.

Haestad Methods
Waterbury, CT
Web: www.haestad.com

Gate valves

Click here to enlarge image

Neo Valves' Seguro Resilient Seal gate valves are available in sizes up to 66". They provide a bubble-tight design and 100% full port areas on all sizes. The valves are available in a variety of pressure classes and multiple lay lengths. All sizes are available with by-passes, Viton seals and Flange X MJ.

Neo Valves
Toronto, Canada
Web: www.neovalves.com

Tapping sleeve

Click here to enlarge image

PowerSeal's Model 3490 High Pressure Stainless Steel Tapping Sleeve now is available with a totally stainless steel mechanical joint outlet. The sleeve allows tapping valve installations to use less expensive mechanical joint resilient wedge valves. Components include heavy gauge stainless construction, drop-in bolts, full circle mat gaskets, mechanical and hydrostatic sealing branch gaskets, five retaining rings to prevent cold flow, and an all-stainless steel mechanical joint connection gland.

PowerSeal Pipeline Products
Wichita Falls, TX

PVC fittings

Click here to enlarge image

Harrington Corp. manufactures gasketed joint Harco brand PVC fittings for C900 PVC pipe, sizes 4", 6" and 8", gasketed PVC fittings for SDR 35 & 26 PVC sewer pipe, size 4" through 15" and gasketed PVC fittings for IPS, SDR 21 & 26, sizes 11/2" through 8".

Harrington CorporationLynchburg, VA

Cleaning robot

Click here to enlarge image

Weda Water has introduced the new VR-600 to its line of underwater cleaning and inspection equipment. The submersible unit is used for cleaning and inspecting drinking water reservoirs, tanks and clear wells while they remain on line. It is remotely operated to ensure that no human contact occurs with the drinking water, eliminating the need for divers. It uses rotating brushes, in tune with a submersible pump to pull the agitated sediment out, ensuring no turbidity. The unit also comes equipped with high intensity lights, adjustable cameras and sonar for real time inspection images and reservoir mapping capabilities.

Weda Water Inc.
Export, PA
Web: www.wedawater.com

Meter reading

Click here to enlarge image

Logicon offers a family of solutions for the water industry ranging from IT support and services to meter reading systems. Its meter reading systems consist of manual, electronic, walk-by AMR and drive-by AMR products. The company's core product line consists of a ruggedized hand-held device, the VersaTerm®, and the VersaProbe®, which is a true "universal" probe. With the benefits of open architecture, the probe promotes open and competitive bidding on metering equipment.

Logicon Commercial Information Services
San Diego, CA
Web: www.logicon.com/meter

Metal detectors

Click here to enlarge image

Fisher's TW-8800 uses digital signal processing to detect buried lines. Three active frequencies provided by the transmitter and two passive modes for tracing without the transmitter are provided. The multi-frequency receiver is light weight and easy to use. A digital keypad allows the user to select the desired operating mode, set the volume, check the battery level, or activate an LCD backlight. Depth measurement is done at the push of a button. The transmitter allows the user to locate in either a conductive or inductive mode.

Fisher Research Laboratory
Los Banos, CA
Web: www.fisherlab.com

Ozone/Oxygen system

Click here to enlarge image

The SGA64 Ozone/Oxygen System from Pacific Ozone Technology is housed in a corrosion-resistant, stainless steel, floor mount cabinet with fully integrated controls. A more powerful addition to the SGA Series, the new unit produces up to 12.8 lbs./day of high concentration ozone. The small footprint makes the system ideal for a wide variety of medium-sized ozone applications. System features include variable power control, feed gas flow control, output references meter and others. The system can be controlled manually or remotely using a 0-10 vDC signal from a C250 Dissolved Ozone Analyzer/Controller or other proportional control signals.

Pacific Ozone Technology
Brentwood, CA Web: www.pacificozone.com

Plate settlers

Click here to enlarge image
EIMCO® Modular Inclined Plate and FlexKlearTM Plate Settlers provide water clarification. In addition to being self-cleaning, the settlers are tolerant of surges in treatment water flow rates. Whether the facilities are new or existing, 1MGD or 100 MGD, Baker Process can custom design for specific water treatment needs.

Baker Process- Municipal and Wastewater Group
Salt Lake City, UT
Web: www.bakerprocess.com

Vacuum-operated chlorinator

Click here to enlarge image
Vulcan Performance Chemicals' Rio LindaTM generator combines liquid sodium chlorite and chlorine gas. The generator meters the gas through a cabinet-mounted, vacuum-operated chlorinator, which includes a flowmeter as an automatic control valve. A magnetic flowmeter measures and transmits the sodium chlorite flow, which is indicated on a digital electronic controller. Vulcan Performance Chemicals representatives offer expert advice on chlorine dioxide chemistry, and can custom-design the system for each application.

Vulcan Performance Chemicals
Birmingham, AL

Cementitious lining

Click here to enlarge image

SewperCoat® from Lafarge is a technological breakthrough in cementitious material designed specifically for the municipal wastewater industry. The material provides a structural, abrasion and corrosion-resistant protective lining against biogenic corrosion relative to hydrogen sulfide (H2S) found in wastewater environments. The unique mineralogy of SewperCoat is the key to its ultimate performance. In the premix product, both the cement and aggregate are pure fused calcium aluminate. It is used for rehabilitating structures such as manholes, wet wells, lift stations, pipe networks, and treatment plant structures, as well as lining new ductile iron and concrete pipe.

Lafarge Calcium Aluminates
Chesapeake, Virginia
Web: www.LCAinc.com

pH meter

Click here to enlarge image

Hanna Instruments introduces the HI 9025C rugged, waterproof pH meter. This instrument not only measures pH, but also °C and ion concentration and ORP in the mV range. The ABS casing is rugged and waterproof. This instrument has a ±0.01 accuracy and ships complete with the HI 1230B double-junction pH electrode with BNC and 1 m cable, HI 7669/2W temperature probe with 1 m cable, 4 AA batteries, pH 4 and 7 and an HI 9025 protective carrying case.

Hanna Instruments, Inc.
Woonsocket, RI
Web: www.hannainst.com

Plastic pipe

The 50-year-old Plastics Pipe Institute offers valuable information on the use of High Density Polyethylene (HDPE) piping systems in pressure and non-pressure applications including water, sewer, and wastewater systems, and more. It is a major trade association representing all segments of the plastics piping industry interested in broadening opportunities for the effective use of plastics piping. The Institute offers brochures and other material about the versatility and applicability of plastic pipe.

Plastics Pipe Institute
Washington, D. C.
Web: www.plasticpipe.org

Aluminum enclosures

Click here to enlarge image
Hot Box® will feature its aluminum equipment enclosure line during the AWWA show. The company providers enclosures for backflow prevention assemblies, meters, valves and pumps. It will display its new "Low Profile" fiberglass enclosures, the Vent GuardTM air release valve enclosure and the Hot Rok® imitation rock enclosures.

Hot Box
Jacksonville, FL
Web: www.hot-box.com

Portable turbidimeter

Click here to enlarge image

The Micro-TPI portable turbidimeter from HF scientific offers a resolution of 0.01 NTU. Standard features include auto ranging 0-1100 NTU. The instrument tests the turbidity level of a sample and automatically adjusts to the appropriate range. Calibration procedures are initiated with the push of a button ensuring laboratory-accurate readings. A waterproof housing allows sample measuring and cleaning in any wet environment. The turbidimeter can perform more than 1000 tests on a single set of 4 AAA alkaline batteries. The carrying case contains everything needed including battery pack, manual and calibration standards.

HF scientific Inc.
Fort Myers, FL
Web: www.hfscientific.com

GIS software

Click here to enlarge image

ArcInfo software from ESRI is a high-end geographic information system with capabilities for automation, modification, management, analysis and display of geographic information. Because of its open development environment, the software allows users to build custom applications and interfaces. Various extensions are available to extend core functionality. The software runs on a variety of hardware platforms, including UNIX workstations and Windows NT computers.

ESRI
Redlands, CA
Web: www.esri.com

Pipe seal

Click here to enlarge image

The newly designed Hydra-Tight Seal from Severn Trent serves as an internal joint seal and can be transformed into an interlocking sleeving system custom designed to fit any length of pipe, 16" diameter and larger. Seals designed for use in municipal potable water and wastewater pipeline applications are manufactured from EPDM rubber that will not support microbiological growth when used in potable water or in humid aerobic conditions.

Severn Trent Services
Tampa, FL

Insertable valve

Click here to enlarge image
The TransmateTM QuikValveTM can be installed on an operating water line with a simple lateral tap. The valves come in 4", 6" and 8" sizes in cast iron, ductile iron, A/C or PVC C-900 pipe configurations. They can be used in water lines with up to 150 psi ambient pressure. The company also offers the InsertaValveTM which can be installed into 10" and 12" lines. Installation time for either valve is less than two hours, with no loss of pressure and minimal water loss.

Romac Industries
Web: www.romacindustries.com

Ultrasonic flow transmitter

Click here to enlarge image
Panametrics' new AquaTransTM AT868 Ultrasonic Flow Transmitter combines a low-cost flow transmitter with proven ultrasonic flowmeter technology for water and wastewater applications. The flowmeter does not obstruct flow, is easy to install, causes no pressure drop, and needs no maintenance or calibration. The microprocessor-based flowmeter is housed in a NEMA 4X enclosure and can be positioned in an accessible location close to the measurement point by mounting it either on a wall or a 2" pipe stand. The two-line, 16-character, LED backlit, LCD display shows up to four flow parameters in sequence. An RS232 port permits a digital link that allows configuration of the meter using a PC and the included Instrument Data Manager interface software.

Panametrics, PCI Div.
Waltham, MA
Web: www.panametrics.com

Pipe threader

Click here to enlarge image

Ridge Tool's new heavy-duty Model 535 Automatic Threading Machine with 2" capacity features a 2.0 hp induction motor and a three-speed transmission. The motor-transmission combination can handle various pipe sizes and applications. The cycle time for threading 1" pipe is approximately 9 seconds. The automatic chuck is simple and durable. The machine threads 1/8" to 2" pipe, including black, galvanized and stainless steel, as well as 1/4" to 2" bar stock.

Ridge Tool Co.
Elyria, OH
Web: www.ridgid.com

Microfiltration system

Click here to enlarge image

The USFilter Memcor® CMF and CMF-S microfiltration systems use a built-in integrity test that validates the entire system to 6-log removal of giardia and cryptosporidium. The membrane systems use a low-pressure configuration, removing contaminants down to 0.2 micron in size, including suspended solids, particles, colloids, algae, bacteria, yeast, protozoa, cysts and, in some systems, viral contaminants.

USFilter Memcor Products
Warrendale, PA
Web: www.usfilter.com

Pre-engineered plant

Click here to enlarge image

The pre-engineered ActiFloc system from USFilter incorporates the company's Microsand Enhanced Clarification process and Direct Retention Multi-Media Filtration. Standard systems operate from 175 gpm up to 10 MGD, removing turbidity, iron and manganese, color, giardia, cryptosporidium and organics. The units are best applied to surface waters with average turbidity >25 NTU, with spiking conditions over 1000 NTU. Engineered for agility, the system offers quick chemical optimization and instantaneous start-up and shut-down. These water plants are especially suited for flashy waters with rapidly fluctuating raw water sources.

USFilter
Warrendale, PA
Web: www.usfilter.com

Casing spacers

Click here to enlarge image

Raci Casing Spacers are designed to isolate water and sewer pipes from casings. The spacers are manufactured entirely out of HDPE, without metal bolts or attachments. The interlocking segments fit all pipes from 1" to 134" diameters. The spacers provide projections around the entire circumference of the carrier pipe in case it rotates during installation. Spacers can be installed on many types of pipes with varying sizes and weights, including coated or plain concrete, ductile iron, plastic, ribbed and steel pipe. Different support heights allow the spacer to clear bell joints, flanges, couplings and other jointing methods.

Raci Spacers North America
Vernon, BC
Web: www.jrgroup.com/raci.htm

Pipe tools

Click here to enlarge image
Reed Manufacturing will display a variety of pipe tools, including the CrimstrateTM Straightener/Rerounder CSR2. The tool handles 11/2" to 2" K annealed copper. It grips the end of a coil to ease uncoiling, and re-rounds oval tubing or mild kinks so that a tubing cutter will track and the fitting will seal properly. It also provides a safe grip for flaring and guides copper into alignment for fitups. The tool is four to five times faster unrolling and straightening a 40 foot coil of soft copper; even short pieces can be straightened and re-rounded.

Reed Manufacturing co.
Erie, PA
Web: www.reedmfgco.com

Electronic propeller meter

Click here to enlarge image
Sparling Instruments has released the FM104/184 MainLineTM electronic propeller meter. The new meter features fewer moving parts and reduced maintenance. It's battery powered electronic rate/totalizer senses the propeller rotation via a magnetic pickup sensor in the gearbox and translates the pulses to rate and total flow. The electronics are isolated from the flow stream in a NEMA 4X enclosure. The lithium battery is rated for eight years. All meter parameters are held in non-volatile EEPROM memory. Full scale, span, K, engineering units, and dampening parameters can all be modified with an optional programming unit.

Sparling Instruments Inc.
El Monte, CA
Web: www.sparlinginstruments.com

Particle counter

Click here to enlarge image

The USFilter Water Particle Counter is a new generation sensing instrument for filtration monitoring and control, using light extinction technology combined with electronic and opto-electronic components. The instrument is the only particle counter traceable with a microscope procedure to recognized standards. It also has true zero count at sample flow. The metal-enclosed instrument is designed for permanent wall mounted installations and has a laser diode design life of 60,000 hours. Eight size channels can be user selected in a particle size range from 2-200 µm (max. 600 µm: WPC-1028 model) and 1-150 µm (max. 400 µm: WPC-1018 model). The unit is equipped with a four line liquid crystal display to provide particle count data, and data can be remotely accessed.

USFilter Stranco Products
Bradley, IL
Web: www.stranco.com

Enclosures

Click here to enlarge image

Fibox's new MNX polycarbonate or ABS plastic enclosures are designed for housing and protecting electronic components and equipment in harsh environments. The enclosures, UL listed and rated NEMA 4X, 6, 12 and 13, feature two body and four cover depths to offer more than 100 off-the-shelf variations. Polycarbonate covers are available in opaque gray or transparent. The MNX line offers a continuous gasket, molded in place on the enclosure's cover. An optional swing-out interior panel provides a mounting surface, easy component access and protection. The cover features a recessed center to protect membrane keyboards or printed graphic overlays.

Fibox Inc.
Elkridge, MD
Web: www.fiboxusa.com

Bolted steel tanks

Superior Tank Co. provides bolted steel tanks designed to meet or exceed API/AWWA standards for materials, dimensions and strength. Every bolt has a tensile strength of 120,000 psi and is hot-dipped galvanized. Every joint, seam and bolt is sealed with rubber gaskets and guaranteed not to leak. All tanks are available with either flush or extended cleanout openings. Walks and ladders on the tanks conform to all OSHA requirements.

Superior Tank Co.
Santa Fe Springs, CA
Web: www.superiortank.com

Information management

Westin's eVMS (Visual Management Solution) increases the power of information through an integrated business portal that taps business, operations and maintenance databases. On handheld PDAs, PCs and workstations, plant staff to executives can access information tailored to specific needs and have at their fingertips the facts and tools for planning, modeling, and action. Westin has specialized in water and wastewater utilities and the public sector for 20 years. In 500 major consulting, engineering and implementation projects, Westin has leveraged technology to deliver business solutions.

Westin
Rancho Cordova, CA

Dry feeders

Aqua Smart, maker of the water purification product SeaQuest, is featuring individual, commercial and institutional dry feeders at its exhibit. These non-electric dry feeders provide an easy and effective way to treat water with SeaQuest. The individual home/apartment feeders take a 1-2 lb. charge unit that needs refilling every 2-3 months. The institutional and industrial dry feeders use a 30 to 40 lb. charge unit and treat approximately 75,000-100,000 gallons per day. Aqua Smart also offers other units for meeting specific needs.

Aqua Smart, Inc.
Atlanta, GA
Web: AquaSmartInc.com

Process automation

Click here to enlarge image

Bristol Babcock has introduced ControlWave, a new process automation control system. Based on a 586 CPU with multiple I/O modules and serial and Ethernet ports, it has the performance and flexibility to handle water/wastewater applications. The system features Bristol ACCOL extensions to the existing five programming languages offered by IEC 61131-03 software. The system provides local historical data storage and alarming with time stamp to ensure the integrity of all data in the event of an interruption in network communication.

Bristol Babcock Inc.
Watertown, CT

Tank consultants

Click here to enlarge image

For more than 22 years, Tank Industry Consultants has been providing professional engineering services to storage tank owners. TIC maintains a staff of engineers, field technicians and support personnel and offers a line of engineering services for storage tanks ranging from new tank construction to tank demolition. The company offers such services as structural and coatings evaluations, lead paint abatement, pre-maintenance evaluations and inspections.

Tank Industry Consultants
Indianapolis, IN
Web: www.tankindustry.com

Meter test benches

Click here to enlarge image

Mars Co. is a manufacturer of water meter test benches designed to meet AWWA and International standards. The benches offer ±1/4 of 1% accuracy and repeatability. Several models are available, designed to test standard residential meters from 5/8" through 8" sizes, all on one bench, and several models designed to test industrial/commercial meters from 3" through 12". Benches can be custom designed to meet specific test requirements. Mars also supplies calibrated stainless tanks, weight control systems, recirculating systems and fully automatic systems complete with computer databases for inventory control and meter accuracy data.

Mars Company
Ocala, FL
Web: www.marswater.com

Meter boxes

Click here to enlarge image

A.Y. McDonald Mfg. Co. has introduced Longboxes and Yokeboxes to its Water Service Products line. The boxes are complete, compact meter-setting packages installed as a unit. They are used as water meter housings in moderate and warm climates. Longboxes and yokeboxes provide automatic alignment for the meter, which can be inserted any time during or after installation. The body and lid are made of cast iron (ASTM A48, Class 25).

A.Y. McDonald Mfg. Co.
Dubuque, IA
Web: www.aymcdonald.com

Ultrasonic flowmeter

Click here to enlarge image
EMCO Flow System's Sono-TrakTM clamp-on transit time ultrasonic flowmeter is designed to measure liquids in pipe sizes from two to 100 inches. The meters are clamped in place using stainless steel clamps. Typical installations take less than 30 minutes. Available outputs are 4-20 mA, RS-232, RS-485, frequency and dual relay. Accurate up to 0.5% of rate with precise pipeline dimensional measurement and adequate straight run piping, typical field accuracy is 1-2% with 0.1% of rate repeatability.

EMCO Flow systems
Longmont, CO
Web: www.emcoflow.com

Arsenic removal

Click here to enlarge image

ADI International's Media G2® arsenic adsorption technology is a low cost, simple removal system using a patented iron-coated filter media. The system has been used to treat water with up to 1200 ppb arsenic, providing reductions to less than 2 ppb. The process is completely pressurized, and pressure drop through the filters is usually less than 2 psi. The media is ANSI/NSF certified to Standard 61.

ADI International Inc.
Fredericton, NB, Canada
Web: www.adi.ca

Retractable covers

Click here to enlarge image

GTI's new cover system allows tanks to be securely covered while providing access to internal components. Ideal for clarifiers, chlorine contact basins, sedimentation tanks, and aeration basins, the covers contain odors, capture VOCs, eliminate sunlight penetration and prevent splashing. The system is a high performance membrane cover supported on a low-profile aluminum arch frame. The UV protected membrane cover is gas tight and can be quickly detached and rolled up along the frame. The arch frames can be remove for complete access to the tank. Optional hatches allow access without retracting the cover. Off-gas removal piping connects to the cover system.

Geomembrane Technologies Inc.
Fredericton, NB, Canada
Web: www.gti.ca

Remote monitoring

Click here to enlarge image

Telog's RS-33 recording systems for remote monitoring in distribution systems includes a multi-channel recorder, power source options and communications options, including wireless. The recorder typically is used in remote monitoring applications for tank level, lift station operation, pump I&I studies, distribution pressures or rain fall. The multi-channel recorders can be programmed to choose the number of input channels, the types and ranges of the input and programmable recording functions and communications schedules.

Telog Instruments, Inc
Victor, NY
Web: www.telog.com

Backflow prevention

Click here to enlarge image

The new Conbraco models 8" RP and 10" RP reduced pressure principle backflow preventers are now available for sale. The backflow preventers feature the shortest laying lengths in the industry. Conbraco plans to make the models 8" RP-U and -Z and 10" RP-U and -Z available with inlet and outlet elbows within the gate valve envelope. This allows for a short, compact enclosure to house the backflow, resulting in a lower installation cost. The backflow preventers feature the company's new solid brass super flowing, cam-guided, swing-check assemblies (patent pending). Also noticeable is the downsized relief valve assembly fully capable of meeting all agency flow capacities.

Conbraco Industries, Inc.
Matthews, NC
Web: www.conbraco.com

Valve closure systems

Click here to enlarge image
The new MaxProTM Valve Closure System from Powell Fabrication is designed to close the valve on a standard 150-pound or 1-ton chlorine cylinder automatically in the event of a chlorine leak. The system can be used on both vacuum and pressurized systems and is designed for use with air or nitrogen. Powell has been a producer of chlorine containment, handling and processing equipment for more than 30 years.

Powell Fabrication & Manufacturing Inc
St. Louis, MI
Web: www.powellfab.com

Packaged ozone system

Click here to enlarge image
GDT Corp. has introduced packaged, skid-mounted ozone treatment systems for water disinfection and oxidation. The patented GDTTM gas transfer process is at the core of the system. Typically used in a side stream configuration, the modular system can support small and large-scale treatment applications. In the process, high efficiency Mazzei® injectors aspirate ozone gas from a generator providing dynamic mixing and mass transfer. Dissolution is enhanced in a reaction vessel, determined for each application on the basis of feed gas and concentration, operating pressure, reaction rates and desired transfer efficiency.

GDT Corporation
Phoenix, AZ
Web: www.gdt-H2o.com

Pressure controllers

Click here to enlarge image

Battery powered PRV controllers from Radcom provide modulated control of pressure within two pre-set pressure limits. The maximum and minimum pressures are pre-set mechanically to ensure optimum reliability. The electronic controllers are able to proportionally adjust the regulated output to create pre-determined pressure profiles throughout a 24-hour day and offer different profiles for each day or weekday/weekend etc. Remote setting and operation are possible via modem. The system features an on-board alarm system with dial-out facility. The PRV output can be configured for fail-safe operation, by configuring for "fail to high" pressure or "fail to low" pressure.

Radcom Technologies, Inc.
Woburn, MA
Web: www.radcom-usa.com

Pump control valves

Click here to enlarge image

Cycle Stop Valves' pump control valves can change any constant speed pump into a constant pressure, variable flow pump, without variable frequency. The valves provide the energy efficiency normally associated with variable frequency from a mechanical valve. Flow ranges are available from 1 gpm to 10,000 gpm. Cycle Stop also offers prefabricated Chameleon Pumping Stations controlled by the company's valves and pressure switches.

Cycle Stop Valves
Lubbock, TX
Web: www.cyclestopvalves.com

On-site septic systems

Click here to enlarge image
ADS has introduced the BioDiffuserTM Angle Chamber for on-site septic systems. The chamber accommodates 0-22.5° angles and makes universal left and right turns. This allows the diffuser leaching chambers to be installed on contours and varying trench directions. The chambers also serve as a one-foot extension on standard size chambers.

Advanced Drainage Systems
Columbus, OH
Web: www.ads-pipe.com

Leak detector

Click here to enlarge image

SubSurface Leak Detection's LD-12 "Professional's Plus" water leak detector has greater sensitivity and better electronic amplification than the company's LD-10 model. The new amplifier includes several new operating features. Its new limiter switch automatically cuts off all loud sounds greater than 100dB, protecting the user's hearing. The new "Filter Thru" switch bypasses all of the amplifier's filtering, allowing the user to hear everything from 50 Hz to 15,000 Hz. The LD-12 includes a base plate for ground miking on city streets and both a magnet base and a contact rod for leak surveying at hydrants, meters and valves.

SubSurface Leak Detection Inc.
San Jose, CA
Web: www.subsurfaceleak.com

Ultrafiltration membranes

Click here to enlarge image
Infilco Degremont's AquasourceTM ultrafiltration membrane system was developed specifically for drinking water treatment. With a 0.01 micron pore size, the hollow fiber membranes provide finished water that is guaranteed to test less than 0.1 NTU in permeate turbidity and to be free of all pathogens, including bacteria, cryptosporidium, giardia and viruses. The system has received disinfection and log removal credit from a number of U.S. states and from other countries. When influent turbidity levels are high, powdered activated carbon can be added to the system for removal of organic matter, pesticides and other contaminants.

Infilco Degremont Inc.
Richmond, VA
Web: www.infilcodegremont.com

Clarifier control system

Click here to enlarge image

Royce Instrument Corp. has introduced a new Model 2700 automatic control system to optimize sludge removal from clarifiers and settling vessels. The system will monitor up to 32 vessels, controlling the pumps and valves used to draw off sludge. The control algorithm will balance the solids loading across all the settling vessels, maintaining the optimum sludge blanket depth to ensure the desired sludge concentration is maintained. In addition to monitoring and controlling the sludge depth, the control algorithm also will monitor pump usage ensuring that pumps are used evenly, reducing maintenance costs.

Royce Instrument Corporation
New Orleans, LA

Ductile iron pipe

Click here to enlarge image

American Ductile Iron Pipe, a division of American Cast Iron Pipe Co., will exhibit ductile iron pipe and fittings for the water works industry. American manufactures ductile iron pipe in sizes 4-64". The company offers a variety of restrained, grooved, mechanical and flanged joints, as well as river crossing and bell-less push pipe. Cement mortar and PolybondPlus® lined pipe also is available.

American Ductile Iron Pipe
Birmingham, AL
Web: www.acipco.com/adip

Clamp-on flowmeter

Click here to enlarge image
Controlotron's System 1010N permanent clamp-on transit time multifunction flowmeter supports all industry standard data inputs and outputs such as 4-20 mA, 0-10 vDC, RS-232, pulse frequency and alarm relays. The system can measure the flow in pipes from 1/4" to 360" over a range of liquids including raw water, potable water, raw sewage, primary sludge, return activated sludge, waste activated sludge, thickened sludge, digested sludge and a wide variety of chemicals. Options include dual channel or dual path transit-time and/or ReflexorTM mode to measure all full pipe applications.

Controlotron
Hauppauge, NY
Web: www.controlotron.com

Cast coupling

Click here to enlarge image

The new Dresser Style 253 modular cast coupling is designed to provide a faster way to join waterworks piping - cast/ductile iron, AC or PVC - regardless of pipe class. The couplings come in a range of sizes from 2-16" OD. Reducing couplings are available in 2.5" x 2", 6" x 4" and 8" x 6". The Style 253 features a color-coding system intended to reduce inventory requirements. Each coupling follower is color-coded for the type of pipe it is designed to fit. Matching gaskets also are imprinted with the correct color as well as the OD range for ease of identification.

Dresser Piping Specialties
Bradford, PA
Web: www.dressercouplings.com

Gas transmitter

Click here to enlarge image
Analytical Technology Inc. (ATI) introduces a new gas transmitter providing increased flexibility. The Series D12 transmitter for toxic or combustible gas detection is capable of measuring up to 32 different gases by plugging in the appropriate smart sensor. The unit is designed for Class 1, Div. 1, Group B, C & D areas, and also for intrinsically safe applications when run in loop-powered mode. Features and options include: loop-powered, two-wire operation with HartTM communication capability; alarm option providing two internal gas alarm relays and a trouble relay; ModbusTM communication option.

Analytical Technology Inc.
Oaks, PA
Web: www.analyticaltechnology.com

Pipe fittings

Click here to enlarge image

One Bolt Inc. has developed a new fitting for ductile iron and PVC pipe that features a compression O-ring system that can be secured with just one bolt. The system has an integral restraining gland that allows the fitting to be self-restraining. The fittings are constructed of ductile iron and are available in 4" to 12" models. They are lined and coated with fusion-bonded epoxy. One Bolt fittings can be installed with two wrenches and a hammer. The system eliminates the need for multiple parts for assembly during installation and also does not require torquing, beveling of the pipe end or the use of jacks and other power equipment.

One Bolt Inc.
Oxford, AL
Web: www.onebolt.com

Corrosion protection

Click here to enlarge image

Tnemec WaterWorks offers an array of coatings and corrosion expertise. The company offers high-build, VOC-compliant, ANSI/NSF Std. 61 approved epoxies & zinc primers, complete exterior dry-fall systems and high-performance fluoro-urethanes. Pipes, containment and treatment areas are covered with tough, chemical resistant coatings that are formulated to withstand potable, caustic and acidic environments. At this year's exhibit, the company's booth will be staffed by representatives who can recommend a system that meets specific performance and budget requirements.

Tnemec Co. Inc.
North Kansas City, MO
Web: www.tnemec.com

Location markers

Click here to enlarge image

Utilities using electronic marker technology can get deeper facilities detection with 3M's new 1400-Series XR Ball Markers. They have a detectable range of five feet and have no internal power source to deplete. The markers consist of a passive antenna within a water-resistant, polyethylene shell that is impervious to minerals, chemicals, and the temperature extremes normally found underground. The propylene glycol solution within the ball functions to level the reflecting antenna. They are sized to be dropped into a conventional four-foot trench without further excavation, and are fitted with eyelets so they can be tethered to a pipe with an optional tie-down strap if desired.

3M
Austin, TX
Web: www.3m.com

Check valves

Click here to enlarge image

Available in sizes from 2" to 60", Crispin Tilting Disc Valves feature a 55 degree slanted seat that reduces opening and closing times, limiting water hammer. They also offer the lowest head loss values of any check valve, with a 40% increase in flow area through the seat. Manufactured with ease of maintenance in mind, their seats are field replaceable to reduce valve down-time. Standard materials include a cast iron body and stainless steel seat rings. The valves also are available with both top and bottom mounted hydraulic dashpots, and offered in a variety of materials and coatings.

Crispin-Multiplex Mfg. Co.
Berwick, PA
Web: www.crispinvalve.com

Flow recorder

Click here to enlarge image

The portable, battery-powered Meter-Master Model 100EL Flow Recorder converts a meter's magnetic drive signal to a digital output that is stored for later downloading. It is compatible with almost all water meters, small enough to fit inside a residential meter box and easy to set up. The unit uses a patented sensor to pick up the magnetic pulses generated by a meter's drive magnets. No electrical or mechanical connection or adapter is required for most meters (Gear-driven meters, Hersey MHR meters, and Sensus compound meters require available adapters). Meter-Master software for Windows provides a variety of report and graph options.

F.S. Brainard & Co.
Burlington, NJ
Web: www.meter-master.com

Membrane filter press

Click here to enlarge image

Rittershaus and Blecher membrane filter systems, offered by Baker Process, add new dimensions to the operability and performance of the proven chamber filter press technology. They feature shorter cycle times, with increased capacity for existing filter presses or lower investment for new facilities. They also produce drier cake solids, for lower transport and disposal costs for landfill or lower thermal energy costs when drying or incinerating sludge product. The systems have a reduced need for conditioning chemicals, so specific cake solids objectives are possible with significantly lower conditioning chemical requirements.

Baker Process
South Walpole, MA
Web: www.bakerhughes.com/bakerprocess/

Joint restraint

EBAA Iron offers the original Megalug® wedge-action, self-actuating, joint restraint for water and wastewater pipelines. The company manufactures a comprehensive family of products, for all classes of pipe, including Flex-Tend® expansion joints, MegaFlange® flange adapters, and 2000PV® restraints for PVC pipe.

EBAA Iron
Web: www.EBAA.com

Valves

Click here to enlarge image

Spears' PVC, CPVC and PP thermoplastic valves are available in a full line of ball, ball check, swing check, gate, butterfly and diaphragm configurations. Also available are special products such as vented ball valves, butterfly valves with PTFE sleeved seats, and diaphragm valves with PTFE lined diaphragms for use in sodium hypochlorite water treatment applications. For high volume applications, the company produces butterfly valves through 60". Complete factory installed valve actuation and control packages are available. In addition, the company offers a line of injection-molded thermoplastic fittings, unions and flanges, plus fabricated fittings through 36".

Spears Manufacturing Co.
Sylmar, CA
Web: www.spearsmfg.com

Fluid control

Click here to enlarge image

Sentry pulsation dampeners, surge suppressors and suction stabilizers from Blacoh are used to smooth out the pulsating fluid flows created by reciprocating pumps. They are ideal for chemical injection and dosing in municipal water treatment systems. The systems are designed to protect pipes, valves, fittings and sensitive equipment from vibration and fatigue. They can improve accuracy of in-line meters and create a steady flow through filter media. These units can be used on all pump types: piston, diaphragm, peristaltic, metering and air operated double diaphragm pumps.

Blacoh Fluid Control
Riverside, CA
Web: www.blacoh.com

Water meters

Click here to enlarge image

The new Metro-Farnier Enduro 2000 Series fire and domestic water meter is now available. The meters are able to measure flow in a range from 6 gpm to 2800 gpm, all in a compact metered laying length. This is the first meter of its kind that can accurately measure such a wide range of flow with one, compact unit.

Metron-Farnier
Boulder, CO
Web: www.metronfarnier.com

Data logging

Click here to enlarge image

The SCADAPack from Control Microsystems now includes a utility for logging data. Applications for this utility include backup of process data in the event of a system communications failure, as well as conventional recording of historical data. SCADALog, the PC-based companion application, provides retrieval of logged data over full duplex RS232, half duplex communications for radios and modems, and/or dial-up telephone.

Control Microsystems
Kanata, Ontario
Web: www.controlmicrosystems.com

Pressure pipe

Click here to enlarge image

Ultra-Blue Class 150 PVC Molecular Oriented Pressure Pipe with a cast iron OD meets AWWA Standard C909. The pipe attains a high strength by re-orienting the molecular structure in the hoop direction. Ultra-Blue is lighter and tougher than conventional PVC, leading to lower installation costs. The non-corrosive pipe has a larger inside diameter than ductile iron or conventional PVC, providing greater flow capacity and lower head loss. One of the safest and easiest pipes to tap, it won't split from end to end. Its uses include potable water systems, sewer force mains, and water transmission and distribution lines.

Uponor ETI
Denver, CO

Pipe

Click here to enlarge image

Recently approved for potable water, Hobas Pipe also is widely used for corrosive applications. This centrifugally cast, fiberglass-reinforced polymer mortar pipe is suitable for virtually every installation method in new construction and rehab. Inherent corrosion resistance, leak-free, push-together joints reduce installation costs. Non-pressure and pressure classes from 12" to 102" OD are available.

Hobas Pipe
Houston, TX

Folded plate underdrain

Click here to enlarge image

Enviroquip offers a folded plate underdrain air scour system that features an improved media-retaining design. The underdrain eliminates the need for support gravel. The 0.25 mm punched openings allow the filter sand to sit directly on the underdrain and air scour laterals. The low profile design, 6"- 8" vertical height, and no support gravel allows deeper media stacks than previously considered with other underdrain designs. Uniform introduction of air and water through separate conduits provides superior simultaneous air/water backwash. The underdrains are suited for new designs or retrofits in existing filters.

Enviroquip Inc.
Austin, TX

Epoxy coatings

Click here to enlarge image

AquataPoxy and Raven products are high performing, 100% solids, non-toxic epoxies with zero VOCs. For more than 15 years, these moisture tolerant epoxy coatings have succeeded at eliminating infiltration, stopping corrosion, and reinforcing deteriorating brick, precast and steel structures. Raven Lining Systems supports more than 30 certified applicators equipped with the latest in application technology.

Raven Lining Systems
Tulsa, OK
Web: www.ravenlining.com

Pipe bursting

Click here to enlarge image

Utilities can burst and replace ductile iron, steel and lined pipe with the new Grundoburst static pipe bursting system from TT Technologies. Pulled by a hydraulic bursting unit, the cutter head's special cutting wheels split the host pipe. An attached expander spreads and displaces the split pipe into the surrounding soil while simultaneously pulling in the new pipe. Patented Quicklock bursting rods are linked together, not threaded. This saves time, prevents twisting and extends the life of the cutter head over threaded bursting rods.

TT Technologies
Aurora, IL
Web: www.tttechnologies.com

Leak detection

Click here to enlarge image

The Water Hound, from Schonstedt Instrument Co., is designed to pinpoint underground fluid leaks in all types of pipe. Rugged, compact and lightweight, the detector requires a minimum of training. The detector's technology platform combines RISC processor technology with DSP techniques. The units operate with automatic noise velocity speeds, which means they will use the set for specified pipes, or users manually can calculate and set their own noise velocity speeds. Battery charging in (nominally) one hour minimizes equipment down time.

Schonstedt Instrument Co.
Kearneysville, WV
Web: www.schonstedt.com

Contaminant information

Click here to enlarge image

The U.S. Geological Survey offers an Internet site that provides information on the sources, occurrence, transport and fate of a variety of contaminants, including arsenic, microbes, pharmaceuticals, trace elements, pesticides, volatile organics, radionuclides, DBP precursors and more. The agency also offers new reports including "Occurrence of Selected Radionuclides in Ground Water Used for Drinking Water in the United States: A Targeted Reconnaissance Survey, 1998;" "A Retrospective Analysis on the Occurrence of Arsenic in Ground-Water Resources of the United States and Limitations in Drinking Water Supply Characterizations;" and "Contaminants and Drinking-Water Sources in 2001: Recent Findings of the U.S. Geological Survey."

U.S. Geological Survey
Web: water.usgs.gov/owq/dwi

Meter interface

Click here to enlarge image

Schlumberger has released the MAPS Mobile Dual R900 pit and wall meter interface unit. The MIU reads two networked ProRead encoders at once and can be connected to a compound meter or two separate meters. This reduces a utility's material and installation cost. The MIU is a one-way communication device that transmits data using spread spectrum, frequency-hopping technology. Data transmitted by the MIU is received by the Schlumberger MAPS Mobile walk-by or drive-by data collection system and stored for downloading at the utility office.

Schlumberger Resource Management Services
Tallassee, AL
Web: www.slb.com

Ball valves

Click here to enlarge image

Ford Ball Valves are designed for use in water works applications. They are designed to provide tightness in both directions at all pressures, easy turning, nonbinding, and minimum pressure loss. The valves feature a heavy cast body engineered to withstand pipe stresses and working pressures up to 300 PSI. They combine a solid one-piece tee-head and stem with a sturdy stop that is enclosed and protected. The valves are available with a variety of connections including copper, iron, plastic, or direct to meter. Molded Buna-N rubber seats support the ball and make the valve water tight.

The Ford Meter Box Co. Inc.
Wabash, IN
Web: www.fordmeterbox.com

Self-priming pumps

Click here to enlarge image
Gorman-Rupp has introduced the Super T-SeriesTM of self-priming centrifugal pumps. Based on the respected T series solids-handling trash pumps, the new Super T series is designed to double impeller and wearplate life. External adjustment of the shimless wearplate is as simple as a turn of the hand, with no need to realign belts, couplings and other drive components. Easy maintenance of the clearance between the impeller and wearplate decreases downtime and keeps the pump operating at maximum efficiency.

The Gorman-Rupp Co.
Mansfield, OH
Web: www.gormanrupp.com

Web-enabled report package

Click here to enlarge image

The Foxboro Company has introduced a new web-enabled report package, the I/A Series Report Package,® that allows a user to build and distribute reports throughout the enterprise via e-mail, intranet or the Web, or as conventional hard copies. It is ideally suited for municipalities because it simplifies generating government-mandated reports and provides water and waste treatment plant managers, municipal officials, and consulting engineers with access to the reports anytime from anywhere via Web-connected PCs.

The Foxboro Company
Foxboro, MA
Web: www.foxboro.com

Enclosed Screw Pump

Click here to enlarge image

The Internalift pump from USFilter is an enclosed screw pump designed for operation in high-volume applications. Available in a wide range of capacities, the pumps can lift 23,000 gpm of stormwater more than 60 feet. Continuously welded flights form the interior of the pump cylinder, and the cylinder turns as a single unit. This design offers a variety of benefits: no leakage, no friction, no jamming, no plugging and less maintenance is required, and the enclosed design minimizes safety, odor and weather concerns.

USFilter CPC Products
Sturbridge, MA
Web: www.usfilter.com

Clarifier

Click here to enlarge image
The patented Trans-FloTM Clarifier for secondary settling tank applications features a transverse, folded flow pattern for high solids removal efficiency in a rectangular tank. Flow moves along the full length of the tank sidewall, and inlet floor orifices control distribution of the influent mixed liquor flow. Flow enters the tank behind a skirt baffle hung beneath the inlet channel and travels across the tank width and rebounds back toward the effluent collection channel.

USFilter Envirex Products
Waukesha, WI
www.usfilter.com

Valve box covers

Click here to enlarge image

The Knutson Dirt Stopper for valve box covers are durable plastic inserts that keep dirt and rocks from entering the valve boxes and covering up the operating nuts. This keeps the nuts accessible or reduces the number of times they have to be cleaned out for accessibility.

J. C. Utility Sales Inc.
Dallas, TX

Concrete tanks

Click here to enlarge image

For over 40 years, DYK has provided high quality prestressed concrete tanks. The company specializes in the design, construction and prestressing of machine stand-wrapped, prestressed concrete liquid storage tanks. The company's experience encompasses more than 21/2 billion gallons of liquid storage in individual sizes ranging from 80,000 to 33 million gallons, under a wide range of climatic and environmental conditions. By combining DYK's design and construction experience with state-of-the-art prestressing equipment, the company's water and wastewater tanks provide a long life with minimal maintenance.

DYK Inc.
El Cajon, CA

Disinfection

Click here to enlarge image

MIOX on-site generators for water disinfection use only salt, water and electricity to create a mixed-oxidant solution. Mixed oxidants can reduce TTHM formation by 30% to 50%, clean biofilm from the distribution system, and leave a more durable chlorine residual than that left by gas chlorine. The capacity of the largest electrolytic cell to date has been 100 lbs. per day of free available chlorine (FAC). Development is nearly complete on new cells with individual capacities of 250 and 500 lbs. FAC per day.

MIOX Corporation
Albuquerque, NM
Web: www.miox.com

Pipe fusion

Click here to enlarge image

McElroy Manufacturing has added two new machines to its line of self-contained, self-propelled, all-terrain hydraulic fusion machines. The TracStar No. 28 will butt fuse pipe sizes from 2" IPS - 8" DIPS. The 28CU model adds saddle fusion capability of up to an 8" branch on any size main. The TracStar No. 412 will butt fuse pipe sizes from 4" IPS - 12" DIPS. The unit is powered by a liquid cooled diesel engine. The carriage on both machines may be removed for in-ditch use. The rubber tracked units are simple to unload and position under any field conditions, fit in a standard long box truck bed, and are datalogger compatible.

McElroy Manufacturing Inc.
Tulsa, OK
Web: www.mcelroymfg.com

Residual analyzer

Click here to enlarge image

The Wallace & Tiernan Products Depolox® 3 Plus Residual Analyzer continuously measures free or total (combined) chlorine in drinking water applications. Using universally accepted amperometric measurement technology, this analyzer directly measures chlorine residuals and provides an isolated 4-20 mA output signal for control or recording. Integral alarm relays are included. The analyzer also is available in a dual input arrangement for measuring pH or fluoride, along with chlorine. Using an internally buffered sensor, the analyzer measures total chlorine residuals without the need for reagents.

USFilter Wallace & Tiernan
Vineland, NJ
www.wallaceandtiernan.usfilter.com

Hydrant flushing device

Click here to enlarge image

Environmental Enhancement and Technologies has introduced the Direct Discharge version of the Hydro-Guard automatic water distribution system flushing device. The new unit functions like its predecessor except that water discharges through a 2" PVC pipe, allowing flushed water to be connected to the user's choice of discharge (culvert, storm sewer, sanitary sewer, etc.). Powered by a 9-volt lithium battery, the unit can flush water mains any time of the day and for any length of time. The water main flushing schedule is input to the unit's operating module using a hand-held programmer. The flushing schedule is based on a 14-day repeating cycle period with three input parameters: day(s) of operation during the two-week cycle, flush start time, and flush finish time.

Environmental Enhancement Technologies, Inc.
Naples, FL

Drum scales

Click here to enlarge image
Scaletron Industries will exhibit two new scale bases: The Model 4021TM ultra low profile digital drum scale for 18" to 26" diameter drums - loaded on/off occasionally; and the Model 4041TM ultra low profile digital tank/platform scale - in sizes 24" x 24" or 30" x 30"- loading on/off on a regular basis. Both have 4-20 mA output signal and 85/265 vAC standard. They come standard with the ScaletronTM 2nd generation 31/2 digit knob tare indicator. The 41/2 digit knob tare indicator or Model 1099TM Chemical Process Controller are available as options.

Scaletron Industries, Ltd.
Plumsteadville, PA
Web: www.scaletronscales.com

Column filtration system

Click here to enlarge image
The Phipps & Bird Column Filtration SystemTM (CFS) simulates the process of a direct-filtration water treatment plant. It is an accessory to the traditional Phipps & Bird JarTester. The device consists of four or six filter columns (2" ID clear PVC); a series of valves for controlling the flow of water from the sample beakers or for use in the backwashing process; and a castered rack. The CFS can be used in the lab or rolled to a more convenient location within the treatment plant. After water samples are agitated through the flash and flocculation stages they are allowed to gravity drain through the filter columns, producing a simulated "clean" water sample.

Phipps & Bird, Inc.
Richmond, VA
Web: www.phippsbird.com

Product certifications

Click here to enlarge image

Underwriters Laboratories has introduced a new Mark specifically for its Environmental and Public Health (EPH) programs. Products receive the mark only after they have been thoroughly investigated by UL chemical, toxicological and engineering specialists using appropriate EPH standards. For more than a century, UL's priority and strength has been enhancing public safety. The company brings that commitment to the municipal water industry through its extensive EPH services, including evaluation of drinking water treatment units, water additives and component products to determine potential health effects.

Underwriters Laboratories Inc.
Northbrook, IL
Web: www.ul.com/newmark

Mechanical fittings

Click here to enlarge image
Perfection Corporation has introduced the HydrosertTM line of NSF-listed polyethylene (PE) couplings, tapping tees and valves for underground service lines. The couplings can be installed without special tools, brass fittings, or expensive equipment. Based on the company's Permasert mechanical joining system for gas piping, the fittings maintain a leak-free seal with a pull-out strength greater than the yield of the PE piping. They are based on a "no-stress" compression design that separates and optimizes both the gripping and sealing areas of the fitting. Once assembled, the pipe or tubing is allowed to rotate freely while the sealing components maintain a positive seal.

Perfection Corporation
Madison, OH Web: www.perfectioncorp.com

Metering systems

Click here to enlarge image

Invensys Metering Systems' exhibit at the AWWA show will feature the company's new absolute-encoder AMR System Register, which provides automated meter reading for MultiJet meters. The register provides greater reading resolution, programming capability and compatibility with existing Invensys RadioRead, TouchRead and PhoneRead AMR systems, which will also be featured. Visitors also can learn about the IMServ metering project and data management services, IMSofTech billing and management software programs, and Invensys' water meters.

Invensys
Uniontown, PA

Valve assembly

Click here to enlarge image

Wilkins' Model 350DA Double Check Detector Assembly is best known for its ease of installation due to short length and light weight. The optional "Setter" saves time in installation. The assembly is easy to disassemble and re-assemble because it requires no special tools and no spring manipulation, which makes examination and cleaning of the check components much easier.

Wilkins, a Zurn Company
Paso Robles, CA
Web: www.zurn.com

Meters

Click here to enlarge image

EnviroBrass® positive displacement, turbine and compound meters are now available through 8". Water utilities have the option of ordering ABB 5/8" to 2" C700 positive displacement meters, 11/2" to 8" T3000 turbine meters and 2" to 8" C3000 compound meters with main cases manufactured of either traditional waterworks bronze or lead-free EnviroBrass. Both traditional and EnviroBrass case meters are available with encoder or digital registers for connection to the most advanced reading systems.

ABB Water Meters
Ocala, FL
Web: www.abb.com/metering

Metering injector

Click here to enlarge image

Blue-White Industries is introducing the all-new Flexflo® A-100NE Series Peristaltic Metering Injector. The new injector can receive 4-20 mA, 0-10 vDC and pulsed signal inputs for automatically adjusting the output of the injector. Additional features include extended tube life, high pressure capability, self-priming, even against line pressure, advanced cooling system, all ball bearing gear motor, and weather resistant housing. The unit has an output capacity of up to 95 GPD. Units have a 3/8" tube assembly constructed of top quality PVDF.

Blue-White Industries
Westminster, CA
Tel: 714-893-8529
Web: www.bluwhite.com

Check valve

The Swing-Flex® Check Valve is designed to be maintenance free. The Memory-Flex® Disc, the valve's only moving part, can be replaced without removal of the valve from the line. The valve's unrestricted, full flow design makes it an excellent choice for slurries and sludge, even in vertical flow-up applications. When provided with optional rubber lining, the valves are suited for highly abrasive and corrosive applications.

Val-Matic® Valve
Elmhurst, IL
Web: www.valmatic.com

Inclined plate separator

Click here to enlarge image

The LME® inclined plate separator clarification process by USFilter's Zimpro Products is designed to remove and thicken suspended and flocculated solids from municipal and industrial waters and wastewaters. It does so in one step, while also reducing turbidities. The basic system consists of rapid mixing and flocculation tanks, followed by a lamellar flow inclined plate section with either a sludge thickener or a sludge hopper underneath and a solids recirculation system. The separator can increase the efficiency of the sedimentation process and provide a footprint reduction of up to 90% over a conventional sedimentation/clarification system.

USFilter's Zimpro Products
Rothschild, WI
Web: www.zimpro.usfilter.com

Filter media

Northern Gravel supplies filter media that meets or exceeds the standards of consulting engineers and those recommended by the American Water Works Association. The company's products are NSF listed. From single bag orders to multiple carloads, Northern Gravel meets specific needs with tolerances from 0.25 mm to 2.5 mm. The company's sand is hard, not smooth, and free of soluble particles. To assure chemical quality, the company uses the most modern equipment for washing, drying, screening and testing.

Northern Gravel Co.
Muscatine, IA
Web: www.northerngravel.com

Backflow preventer

Watts' new Copperhead Series 995 reduced pressure backflow preventer is designed to protect the potable water supply in accordance with national plumbing codes and water authority requirements. The 995 can be used in a variety of installations, including health hazard cross connections in internal piping systems and for containment at the service line entrance. This series features two in-line, independently operating modular check valves, a bottom mounted hydraulically operated differential relief valve, two ball valve shutoff valves, four test cocks, and is serviceable without the use of special tools. Features include a tubular, lead-free copper body, external/internal nickel-plated body that acts as an oxygen barrier for corrosion resistance, and more.

Watts Regulator Co.
North Andover, MA
Web: www.wattsreg.com

Metering pumps

Click here to enlarge image

LMI is a leading manufacturer of solenoid and motor-driven chemical metering pumps and control equipment (pH & ORP) for the municipal water/ wastewater industry. The Series G pump has a maximum output of 300 gph, and maximum pressure of 150 psi. Variable speed drives are available to simplify automation, and liquid ends are available for most water treatment chemicals including polymers and lime slurry. The company's newest solenoid pumps include the Model C76, rated at 4.0 gph at 175 psi for higher pressure systems, and the new Model P7, a low cost pump for smaller automated systems. All of LMI's solenoid pumps are simple to automate with a pulse or mA input.

Liquid Metronics Inc. (LMI)
Acton, MA
Web: www.lmipumps.com

Certification program

Click here to enlarge image

The NSF Drinking Water Additives Program is responsible for the certification of drinking water treatment chemicals and drinking water system components to ensure that these products do not contribute contaminants to drinking water that could cause adverse health effects. ANSI/NSF Standard 60: Drinking Water Treatment Chemicals - Health Effects is the nationally recognized health effects standard for chemicals which are used to treat drinking water. ANSI/NSF Standard 61: Drinking Water System Components - Health Effects is the standard for all devices, components and materials which contact drinking water.

NSF International
Ann Arbor, MI
Web: www.nsf.org

Vertical turbine pumps

Click here to enlarge image

Patterson Pump will feature its PVT vertical turbine pump at the AWWA exhibition. The PVT is offered in 12" to 40" bowls, with the ability to handle flows in excess of 30,000 gpm. The pumps can be staged as necessary to meet desired pressure requirements. Other Patterson water pumps include horizontal and vertical centrifugal pumps; horizontal split case pumps; vertical in-line pumps; axial and mixed flow pumps for flood control; multi-purpose vertical turbine pumps; end suction pumps and prepackaged pump systems.

Patterson Pump Co.
Toccoa, GA
Web: www.pattersonpumps.com

Pig tracker

Click here to enlarge image

Pipeline Inspection Company's Spy® Pig Tracker is an electronic locating system that tracks the passage and pinpoints the location of pipeline pigs. The system uses strong, low frequency signals with a long signal life. The system consists of a cylindrical transmitter that travels with the pig, and a hand-held pickup wand and receiver unit that informs the operator of the pig's location.

Pipeline Inspection Company, Ltd.
Houston, TX
Web: www.picltd.com

Potable water pipe

Click here to enlarge image
Performance PipeTM Bluestripe® Potable Water Pipe, produced to AWWA C901 and C906 standards, is available with NSF certification and manufactured in iron pipe and ductile iron OD sizes. The pipe has multiple blue stripes running lengthwise along the pipe for permanent identification as potable water piping. The flexibility and strength of polyethylene make the pipe an ideal material for all water applications. Performance Pipe, a division of Chevron Phillips Chemical Co., manufactures polyethylene pipe and fittings, and custom fabricated structures. Performance Pipe came to life as a result of the merger between PLEXCO (formerly of Chevron Chemical Co.) and Phillips Driscopipe (formerly a division of Phillips Petroleum Co.).

Performance Pipe, a division of Chevron Phillips Chemical Co.
Richardson, TX
Web: www.performancepipe.com

Storage tanks

Pittsburg Tank & Tower Co. offers ground and elevated storage tanks for both potable and wastewater. Tanks are designed, fabricated and field erected to the customer's specifications. The company also provides feasibility studies, moves existing tanks, raises and lowers tanks, and updates tanks to current OSHA and EPA requirements and seismic standards. Emergency service is available 24 hours a day for existing tanks.

Pittsburg Tank & Tower Co.
Henderson, KY

Valve actuator

Click here to enlarge image

The new Hexacon Controller from Halogen Valve is a battery operated emergency chlorine and SO2 valve closing system that has the ability to control up to six Eclipse Actuators. In an emergency, this system will shut off a chlorine gas ton or 150 lb. cylinder container in less than a second, when the valve is open one full turn. The actuator will react to inputs from gas sensors, seismograph sensors, fire alarms, panic buttons and other close switch indicators.

Halogen Valve Systems Inc.
Irvine, CA
Web: www.halogenvalve.com

Security products

Click here to enlarge image

The Intimidator water security products from McGard use a unique locking pattern technology and install in the field with no modifications to existing equipment. Each lock installs and removes with its matching key tool. The computer-designed extra-narrow groove patterns in the security products can be adapted to a variety applications. Key registration and computerized tracking of key codes assures that no unauthorized keys will be distributed.

McGard Special Products
Orchard Park, NY
Web: www.mcgard.com

UV disinfection

Click here to enlarge image

Trojan's municipal drinking water disinfection system, the UVSwift, features flexible lamp cleaning technology, a small footprint, increased reactor efficiency for maximized power efficiency and advanced controls ensuring adequate UV radiation. Recent findings have proven that UV is effective in eliminating disease-causing pathogens that are resistant to conventional chemical disinfection. A safe alternative to chemical disinfection, UV does not alter the taste, color or odor of water.

Trojan Technologies Inc.
London, ON
Web: www.trojanuv.com

Particle Counter

Click here to enlarge image

GLI is introducing the AccuCount+ Particle Counter, designed specifically for the drinking water industry. The instrument measures particles from 2 to 800 microns in five separate user-selectable size ranges. The sapphire measuring cell design is capable of measuring up to 20,000 particles per milliliter at an accuracy of better than 90%.

GLI International Inc.
Milwaukee, WI
Web: www.gliint.com

Ballasted flocculation

Click here to enlarge image

USFilter Kruger Products offers the Actiflo® ballasted flocculation process for high rate clarification. The system takes a typical chemical floc and attaches it to a particle of sand. The end result is "floc on a rock." By using microsand as a seed for floc formation, the company has developed a flocculation/sedimentation process that is up to 20 times smaller than conventional clarification. The microsand allows for more effective removal of solids, organics, pathogens, and other typical water contaminants. It also stabilizes the process during sudden fluctuations in raw water quality.

USFilter Kruger ProductsCary, NC

Acoustic flow measurement

Click here to enlarge image

Accusonic Technologies is a supplier of acoustic flow measurement systems for use in pipelines, conduits, and open channels. Its multiple-path acoustic transit-time technology is recognized for high-accuracy flow measurements in large-diameter pipes and open channels. The company also designs and manufactures a line of Doppler-shift area-velocity flow monitors for use in gravity-flow culverts, pipes, small open channels and streams. The Model 7510 transit-time flowmeter console is designed for flow measurement in large pipes and open channels.

Accusonic Technologies Inc.
E. Falmouth, MA
Web: www.accusonic.com

Tank services

Utility Service Co. is a nationwide provider of integrated services for potable water storage tanks and distribution systems. Its services include limited and full-service maintenance programs for tanks, wireless antenna site installation, management of communication facilities at tank sites, and complete water pipe rehabilitation using trenchless technology. New tanks and special financing also are offered through USCI-Caldwell, the company's joint venture partnership with Caldwell Tanks, Inc.

Utility Service Co.
Perry, GA
Web: www.utilityservice.com

Treatment plant products

Click here to enlarge image

The line of Trumbull treatment plant products has been expanded with the addition of the new Indicating Floorstand. The tool line includes ratchet box wrenches with enclosed gearing and double socket ratchet wrenches. A new adjustable handle socket wrench and a new 1/4 turn lever wrench have been added to the line. Also, a line of hydrant safety repair kits is available from stock, as are various hydrant valve rubbers.

Trumbull Industries
Youngstown, OH

Backflow preventer

Click here to enlarge image

FEBCO has introduced its latest backflow prevention assembly since its "N"-shaped Masterseries models were introduced in the early '90s. The Microseries Model 830, recently approved by ASSE in the 4" size, is the most compact, lightest weight backflow prevention assembly ever produced. By incorporating integral butterfly valve shutoffs and advanced modular check valves, the assembly offers lay lengths that are the shortest in the industry. The 4" Microseries Model 830 Double Check assembly with shutoffs is only 22" in length.

CMB Industries
Fresno, CA
Web: www.cmb-ind.com

Infrastructure development

With more than 4,500 professionals in over 30 nations, Montgomery Watson clients benefit from its more than 150 years of expertise in global infrastructure development. Over the years, Montgomery Watson has engineered, constructed, financed and managed many of the world's largest and most technologically complex infrastructure projects. Clients include a wide range of municipalities, industrial plants, mining concerns, multinational companies and governments around the globe. Following its merger with Harza Engineering in May, the company has been renamed MWH.

MWH
Pasadena, CA, and Broomfield, CO
Web: www.mw.com

SCADA systems

For over 26 years, EMA has been providing solutions to meet technology and business management needs of utilities, public works and municipalities. The company specializes in planning, designing, implementing, and integrating process control and SCADA systems, and other technologies. The company's technology expertise includes strategic technology planning, information systems, control systems, technology infrastructure, and modeling/process optimization.

EMA, Inc.
St. Paul, MN
Web: www.ema-inc.com

Sponsored Recommendations

April 25, 2024
Discover the transformative benefits of leveraging a scalable On-Machine I/O to improve flexibility, enhance reliability and streamline operations.
April 25, 2024
The world of manufacturing is changing, and Generative AI is one of the many change agents. The 2024 State of Smart Manufacturing Report takes a deep dive into how Generative ...
April 25, 2024
The world of manufacturing is changing, and Generative AI is one of the many change agents. The 2024 State of Smart Manufacturing Report takes a deep dive into how Generative ...
March 15, 2024
Alarm notification software enables faster response for customers, keeping production on track
