Solar Powered System Feeds Caustic/Acidic Chemicals

A new weatherable solar powered chemical dosing system features a non-metallic, peristaltic pump for corrosion-free transfer of caustic and acidic treatment chemicals from an integral thermoplastic storage tank to water and wastewater containment facilities in remote locations.

Pennwell web 350 280

A new weatherable solar powered chemical dosing system features a non-metallic, peristaltic pump for corrosion-free transfer of caustic and acidic treatment chemicals from an integral thermoplastic storage tank to water and wastewater containment facilities in remote locations.

The pump, Flex-I-Liner® Model 12, uses a rotor mounted on an eccentric shaft to push fluid trapped between a flexible elastomer liner and a solid plastic body block. The self-priming design has no seals to leak or valves to clog and can run dry without damage.

Available from Vanton Pump and Equipment Corp., the pump features a rigid body block molded of solid polypropylene, UHMW polyethylene or PTFE, and the flexible liner of natural rubber, neoprene, Hypalon, Viton or Nordel. This eliminates corrosion associated with pumps constructed of stainless steel and high alloys, and wicking and delamination associated with fiberglass and plastic-lined metals, according to the company.

Pennwell web 350 280

Suitable for flows to 2 gpm and pressures to 25 psig at temperatures to 185°F, the pump is designed to meter a fixed volume of liquid over user-programmed time intervals. A throttling valve on the suction line to the pump allows flow rate adjustment.

A 40 watt photo-voltaic solar panel charges a 12 vDC deep cell battery that can power the pump's 1/6 hp DC motor on a single charge for three hours continuously, or cumulatively over several days of intermittent operation during which the pump is started and stopped manually, or automatically according to user-programmed dosing schedules.

Also inert to water and wastewater treatment chemicals are the system's base plate and 20 gal tank constructed of solid polypropylene, polyethylene or PVC. The controls are housed in a fiberglass NEMA IV weatherproof enclosure.

An optional manifold with nozzles is available to spray treatment chemicals such as alum, ferric chloride, hydrofluosilicic acid, polymer, sodium hydroxide, sodium hypochlorite or sulfuric acid over a desired area for control of odor, insects or algae in water treatment facilities, recreational areas, farms, deserts and other remote sites.

The self-contained system measures 32 in. L x 24 in. D x 15 in., weighs 225 lbs and is available mounted on casters. Other solar powered feeding systems equipped with larger Flex-I-Liner pumps and larger solar panels handle flows to 10 gpm.

The company also manufactures stand-alone peristaltic pumps as well as horizontal centrifugal thermoplastics pumps, vertical centrifugal thermoplastic sump pumps, and integrated non-metallic tank/pump systems with flows to 1450 gpm at heads to 400 ft.

For more information on the solar powered dosing system, visit the company's website at www.vanton.com.
