Products & Services: Meters & Meter reading equipment

Master Meter's Dialog 3G Interpreter Register is a universal AMR upgrade that replaces the existing register on most any brand meter in minutes

Pennwell web 210 215

Universal AMR register

Pennwell web 210 215

Master Meter's Dialog 3G Interpreter Register is a universal AMR upgrade that replaces the existing register on most any brand meter in minutes – without service interruption. The Interpreter features the company's ConnectionFree™ design, housing all vital AMR components – encoder, RF transmitter, battery and antenna – safely within the register's sealed stainless steel and tempered glass enclosure. The register works with the 3G AMR system, which provides a mobile read infrastructure that is fully migratable to fixed network AMR/AMI applications.
Master Meter Inc.
Mansfield, TX
Tel: 800-765-6518
Web: www.mastermeter.com
DistribuTECH 2010: Booth 1041
Circle No. 228 on Reader Service Card

Flow meter

Pennwell web 219 166

Municipal water engineers tasked with measuring liquid flow from water storage reservoirs or lakes as it enters treatment facilities will find the space-saving V-Cone® Flow Meter from McCrometer easily fits in crowded equipment installations where long pipe straight-runs are impractical. The meter features built-in flow conditioning. It reduces flow meter straight pipe run requirements by up to 70 percent or more and needs only 0-3 straight pipe diameters upstream and 0-1 downstream to operate effectively.
McCrometer
Hemet, CA Tel: 800-220-2279
Web: www.mccrometer.com
Circle No. 230 on Reader Service Card

AMR leak detection

Sensus and Fluid Conservation Systems (FCS) are pairing their products – Sensus' FlexNet® and FCS' Permalog+ AMR – to provide an acoustic leak detection solution that can be used to enhance customer service, curb revenue loss due to leaks, and promote conservation efforts of any size water utility. FlexNet is a wireless fixed-base data collection and communication system which employs a primary-use, licensed radio spectrum to transmit data at up to two watts. Permalog is an acoustic noise logger which detects vibrations caused by leaks in water pipes. The units listen during the night when ambient noise is at its lowest.
Sensus
Raleigh, NC
Tel: 919-845-4007 Web: www.sensus.com DistribuTECH 2010: Booth 1521
Circle No. 229 on Reader Service Card

Single-jet meters

The Spectrum Single-Jet Meter from Metron Farnier is the widest range single measuring element meter available to US utilities. The meters have been designed to replace compound type and turbine type meters for commercial services. The meters feature a 1000:1 turndown ratio and superior low flow registration. They are unaffected by sand or small debris in the line and have no straight pipe requirements upstream or downstream of the meter. The meters can be combined with AMR/AMI systems from Transparent Technologies to help reduce unaccounted for water and increase revenues.
Metron Farnier Inc.
Boulder, CO
Tel: 800-763-8766
Web: www.metronfarnier.com
Circle No. 232 on Reader Service Card

Wide area network

Aclara has introduced a mesh-based wide-area network for utilities. The Aclara Smart Communications Network is a high-bandwidth, standards-based, broadband solution that will bring together existing utility assets and applications into a single network. The network is designed for use by water, gas or electric utilities and employs TCP/IP communications protocols as well as IEEE 802.11 standards for wireless communications. It allows utilities to replace multiple, low-to-medium bandwidth systems that now communicate data to utilities. The system provides an interface to utility and IT resources and back-office applications for SCADA control and monitoring systems, advanced metering infrastructure (AMI), home-area networks, and mobile-workforce applications.
Aclara, Utility Solutions Group of ESCO Technologies Inc.
Cleveland, OH
Web: www.aclara.com
DistribuTECH 2010: Booth 739
Circle No. 231 on Reader Service Card

Flow measurement solutions

Pennwell web 210 232

Badger Meter's residential and commercial metering technology is designed for optimal system performance, superior reading and billing accuracy, and maximized revenue generation. The company offers AMR/AMI, reading data management equipment, meters and turnkey support services for utilities. The Badger Orion Water Meter Monitor helps utilities improve customer service by providing end consumers with a way to proactively monitor and conserve their water usage. Compatible with all Orion transmitters, the unit uses state-of-the-art receivers. The unit also includes a leak notification feature.
Badger Meter, Inc.
Web: www.badgermeter.com DistribuTECH 2010: Booth 631
Circle No. 233 on Reader Service Card

Water consumption monitoring

Neptune offers the tools to capture data that utilities need to monitor their water consumption and infrastructure performance. Its ARB® FixedBase™ System with synchronized midnight reads and 24-hour consumption intervals provides utilities with a precise snapshot of their entire system – a valuable tool in identifying and managing Non-Revenue Water. The ARB® Hybrid™ System with R900® GPRS Gateway moves utilities toward a more advanced AMR system by allowing them to capture data from a large group of targeted meters. The company's Technolog CELLO, a new battery-powered data logging device with built-in GSM/GPRS modem, provides hourly reads for Industrial, Commercial, or Institutional (ICI) meters.
Neptune Technology Group Inc.
Tallassee, AL
Tel: 800-633-8754
Web: www.neptunetg.com
Circle No. 234 on Reader Service Card

Electromagnetic water meter

Pennwell web 210 221

Krohne has introduced the Waterflux 3070, a new electromagnetic water meter for applications in the water and wastewater industry. Its 15 year battery life makes it ideally suited to applications where no power is available. The device also has the option of a GSM module for remote transmission of measurement data and status information. Thanks to extremely short inlet and outlet installation requirements, the meter can be installed in very narrow wells and chambers.
Krohne
Peabody, MA
Tel: 800-356-9464
Web: www.krohne.com/northamerica
Circle No. 236 on Reader Service Card

Composite meter

Pennwell web 210 213

Hersey Meters has introduced the Model 420 composite positive displacement meter; the latest addition to its line of products for the water industry. The new meter incorporates patented stainless steel thread design and a unique bottom plate for added dimensional stability and strength in a true lead-free composite meter solution for residential applications. Extremely accurate and lightweight, the meter makes installation simple with integral gaskets and is compatible with AMR/AMI solutions when equipped with Hersey's Translator encoder register.
Hersey Meters
Cleveland, NC
Tel: 800-323-8584
Web: www.herseymeters.com
Circle No. 235 on Reader Service Card

Lithium batteries

Pennwell web 210 250

Tadiran Batteries has introduced an improved version of its PulsesPlus™ battery, which now provides an indication when nearing its end of life, allowing users to maximize the service life of the original battery while at the same time ensuring continuous service through scheduled battery replacements. Lithium thionyl chloride batteries are typically used in applications where battery replacement or recharging is either impossible or extremely difficult. The new improvements come in two distinct families: A 3.6v system with a 5% end-of-life indication (when the battery uses up 95% of its capacity, a remote indicator can advise the end users that 5% of operating life remains), and a 3.9v system with a 10% end-of-life indication.
Tadiran Batteries
Port Washington, NY
Tel: 516-621-4980
Web: www.tadiranbat.com
Circle No. 237 on Reader Service Card

Transit-time flowmeter

Pennwell web 210 179

Shenitech has announced availability of its new third generation STUF-300F1B Wall-Mount Transit-Time Flowmeter. Designed for nonintrusive pipe flow measurement, the flowmeter uses a pair of clamp-on ultrasonic transducers to measure flow from outside the pipe. The meter's +1% accuracy (+0.5% with on-site calibration), nonintrusive design eliminates contact with process liquids and requires no maintenance. The meter accommodates a wide pipe range from 1" to 240" diameter.
Shenitech, LLC
Tel: 888-738-0188
Web: www.shenitech.com
Circle No. 238 on Reader Service Card

Ultrasonic flowmeter

Pennwell web 210 189

The ECHO "Arrow Hunter Plus" is a clamp-on transit-time flowmeter for clean or dirty liquids. It will measure flow in metal or plastic pipes with any liners from 3/8" to 118" diameters. It uses Dual DSP technology and measures flow velocity from 0.03 to 82 ft/s. Accuracy is ± 0.5% factory calibrated (process conditions can reduce accuracy) and repeatability of ± 0.15% of measured value. The meter can measure any municipal flow application, including low-flow chemical feed to large concrete-lined raw sewage pipes.
ECHO Process Instrumentation Inc.
Shalimar, FL
Tel: 850-609-1300
Web: www.echopi.com
Circle No. 239 on Reader Service Card

Integrated meter, AMR

Pennwell web 210 208

Itron combines meter accuracy and meter module reliability into a single wireless offering for a new meter/AMR solution. The new 80W-i meter module is built on the company's proven module performance and is bundled with the Flostar, Multimag and Woltex meters that are known for their accuracy over a wide range of flow rates. The 80W-i integrates with the meter register wirelessly for ease of installation and offers advanced leak, reverse-flow and tamper detection, all powered by a 20 year battery.
Itron Inc.
Liberty Lake, WA
Tel: 800 635-5461
Web: www.itron.com
DistribuTECH 2010: Booth 903
Circle No. 241 on Reader Service Card

Metering systems

Pennwell web 210 219

Elster AMCO Water offers metering systems specifically designed for North American water utility, submetering and commercial and industrial applications. Its SmartMeter™ is a residential solid state water meter that offers improved accuracy throughout the flow range. The meters are available as visual read meters or in a fully AMR/AMI enabled format using inductive touch pads, mobile AMR or fixed network AMI. The meters have no moving parts and are unaffected by grit and particulates, including sugar sand. The meter does not measure air and retains its accuracy throughout its entire lifetime.
Elster AMCO Water
Ocala, FL
Tel: 352-732-4670
Web: www.us.elster.com
DistribuTECH 2010: Booth 1603
Circle No. 240 on Reader Service Card
