Retractable Covers Control Odors, Improve Wastewater Tank Access

The Vallejo Sanitation & Flood Control District, in the San Francisco Bay area, has been engaged in a program to scrub off-gas odors from all aspects of its wastewater treatment plant.

Mar 1st, 2010
Pennwell web 300 385

By Jim McMahon

The Vallejo Sanitation & Flood Control District, in the San Francisco Bay area, has been engaged in a program to scrub off-gas odors from all aspects of its wastewater treatment plant. Early in the project, the district had covered all of the facilities in its headworks and primary treatment steps to control off-gas. Later, it developed a novel approach for the management and disposal of its biosolids, including designing a specialized hopper for storage of the plant's dewatered solids and an automated truck-fill process for transportation of the solids to a district-owned landfill – Tubbs Island – again minimizing off-gas release.

Recently, the wastewater plant has focused on scrubbing off-gas odors from its secondary treatment processes, and specifically its two open aeration basins. To contain these odors, the district opted to use a retractable, structurally supported geomembrane cover system from Geomembrane Technologies Inc. (GTI), which has not only proven effective for the collection of off-gas, but has also provided simplified access for tank monitoring, maintenance and repairs.

Vallejo Sanitation District

The Vallejo Sanitation & Flood Control District is an independent special district created by the State of California to collect and treat wastewater, and to protect the Vallejo community from flooding. Since 1952, the District has protected public health and the San Francisco Bay by collecting and treating the wastewater generated by more than 115,000 residents of Vallejo and the surrounding area.

A ventilation system draws air through the tank and underneath the covers, and pulls along with it the off-gas from the aeration process. Off-gas removal piping is connected directly to the cover system and out to a soil filter for odor scrubbing.

The district has a tradition of innovative use of technology in wastewater handling. It has been recognized by the EPA and awarded the National First Place Award as the most outstanding project involving land application of biosolids in the United States. The plant disposes of 20,000 cubic yards of biosolids per year, where it is used as a soil amendment to improve farmland. The plant differs from most in that it uses no digesters in its process.

The Vallejo facility is permitted to treat 15.5 million gallons per day (mgd), but has the capacity to provide full secondary treatment of 35 mgd. During wet weather, the plant is capable of processing 25 mgd primary treatment, combined with the 35 mgd secondary treatment for a total of 60 mgd.

Treatment Process

Passing through Vallejo's primary water treatment units – its headworks, grit chamber and primary clarifiers – where the solids are separated out, the liquid part of the waste stream flows to the plant's secondary treatment for biological processing.

Vallejo's secondary treatment process is a trickling filter/solids contact process, consisting of four main treatment steps – biotowers, contact aeration basins, secondary clarifiers and disinfection.

The trickling filter part of the process is provided by two biotowers, which receive effluent from the primary clarifiers. The wastewater is sprayed down over plastic media in the filter providing a surface for bacteria to grow and consume the organic material in the effluent. The water is run through the biotowers twice, essentially removing 99 percent of the organic material running through the secondary treatment.

After biofiltration, the wastewater is pumped into two aeration basins. The aeration tanks condition the solids particles discharged from the biotowers, so they settle more readily in the downstream secondary clarifiers. Blowers and fine-bubble diffusers mounted on the floor of the basins introduce air that is necessary for the flocculation of particles, converting the organic solids into heavier clumps that settle and are removed by sedimentation in the secondary clarifiers.

Leaving the contact aeration tanks, the flow continues to the secondary clarifiers, where bacteria and fine organic substances settle out of the wastewater. The wastewater then enters contact basins where it is mixed with sodium hypochlorite, followed by sodium bisulfite to remove residual chlorination, before it is pumped into Mare Island Strait via a 2.5-mile-long pipeline.

Aeration Basin Covers

The Vallejo plant's two secondary process aeration basins were originally built in 1988, and are each 15 feet deep, 15 feet wide and 110 feet long. For almost 20 years the basins remained uncovered, but as part of the plant's odor control upgrade, the district looked into options for covering them. Carollo Engineers was retained by Vallejo to handle the design and construction management for the plant odor control upgrade, and began reviewing different cover options for enclosing the basins.

"We wanted the covers first for odor control, so they needed to be corrosion resistant," said Tim Tekippe, Carollo Project Manager handling the Vallejo project. "But we also needed the covers to be easy to open and close for access to the tanks for sampling, scheduled maintenance and repairs. We felt structurally-supported covers would be the best system for the plant's needs because of the better access they provide over other systems."

Vallejo staff and Carollo looked at a number of other wastewater plants, and what they were using to cover their aeration tanks, before selecting the retractable covers, said Barry Pomeroy, Director of Operations and Maintenance at the Vallejo Sanitation & Flood Control District.

The Vallejo aeration basins were covered with a retractable, structurally supported geomembrane cover system that provides odor control yet allows for simplified maintenance access.

Vallejo's new cover system – designed, engineered and built by GTI – consists of a composite sheet of high-strength, UV-protected, coated fabric tensioned across a series of low-profile aluminum arches which span the tank's opening. Intermediate aluminum walkways spanning the tank are used to divide the fabric cover sections into appropriate lengths for retractability.

The geomembrane cover fabric is made up of a laminated sheet of 40 mil specialty PVC (Ethylene Interpolymer Alloy) that acts as a gastight barrier to keep the off-gas from passing through. It incorporates a specialized weave design that provides maximum strength-to-weight ratios. Since this topsheet is exposed to the sun, it is also equipped with advanced UV inhibitors. The material can withstand temperatures to minus 30 degrees F. The cover has exceptional seam strength and puncture and tear resistance, plus low thermal expansion and contraction properties. It is resistant to a wide range of chemicals and offers good dimensional stability under high loads and temperature fluctuations.

Vallejo's covers are gas-tight, operating under negative air pressure. A ventilation system draws air through the tank and underneath the covers, and pulls along with it the off-gas from the aeration process. Off-gas removal piping is connected directly to the cover system and out to a soil filter for odor scrubbing.

The membrane covers can be detached and rolled up along the frame. This gives operators access to inspect and maintain internal components of the basins. Hatches in the intermediate aluminum walkways allow access by plant operators without retracting the covers.

"The expected life of these retractable covers is about 15 years," Tekippe said. "And the cost is very attractive compared to other cover systems. If a cover did have to be replaced it would be easy to change out, and could be done in minimal time. These retractable covers are very well-suited for both municipal wastewater and drinking water plants. We have since specified them for use in other public water and wastewater projects." WW


About the Author:
Jim McMahon writes on water and wastewater systems. His feature stories have appeared in hundreds of industrial and high-tech publications throughout the world. He can be reached at jim.mcmahon@zebracom.net. To learn more about the cover systems from Geomembrane Technologies, visit the company website at www.gticovers.com
