Products & Services: Scada Products

The Jupiter gas detection system (Model HVS4000) monitors and reports information about hazardous and toxic gases to a SCADA monitoring systems.

Jan 1st, 2010
Pennwell web 210 263

Gas detection system

The Jupiter gas detection system (Model HVS4000) monitors and reports information about hazardous and toxic gases to a SCADA monitoring systems. Its features include a sensor life indication, two (250 vAC - 8 amp) settable internal relays, a three-digit display, dual MODBUS connections and 4-20 mA proportional gas level output. The microprocessor-based system detects most toxic gases in parts per million (ppm), including: Ammonia, Carbon Monoxide, Chlorine, Chlorine Dioxide, Ozone, and Sulfur Dioxide as well as Oxygen deficiency.
Halogen Valve Systems Inc.
Irvine, CA
Tel: 877-476-4222
Web: www.halogenvalve.com
Circle No. 242 on Reader Service Card

Turbine meter totalizer

Accutech, a division of Control Microsystems, has announced the launch of the TM10 Turbine Meter Totalizer, a battery powered, wireless instrument that offers flow rate and total accumulated flow volume data for standard turbine meters. The unit measures the volumetric flow rate of liquids or gases by detecting the frequency of pulses generated with a standard turbine meter and applying a user-configured proportional "K" factor.
Control Microsystems
Ottawa, Ontario
Web: www.accutechinstruments.com.
Circle No. 243 on Reader Service Card

Ultrasonic flow meter

The new Portaflow PT500 Transit Time Flow Meter from Greyline is designed for clean liquids like water, oils and most chemicals and is used for troubleshooting, spot checks and balancing flow. Strap-on sensors mount on the outside of plastic or metal pipes and ultrasonic signals are injected through the pipe between the two sensors. It works on any pipe diameter from 0.51 to 78" OD. Features include a large, backlit graphics display, 4-20mA output, data logger, RS232 and USB outputs, a user-friendly operating system with "Quick Start" calibration menu, plus ability to store calibrations for up to 20 different sites.
Greyline Instruments Inc.
Massena, NY
Tel: 888-473-9546,
Web: www.greyline.com
Circle No. 244 on Reader Service Card

Satellite-based remote monitoring

The new Sensaphone SAT4D is designed to monitor remote sites no matter where they are located. It can monitor for equipment failures, leak detection, tank level problems, and more. Instead of relying on phone lines or cell phone services, the system uses direct satellite communications. The result is 100% communication coverage across the United States as well as many other countries.
Sensaphone
Tel: 877-373-2700
Web: www.sensaphone.com
Circle No. 245 on Reader Service Card

Control system

Emerson's Ovation control and SCADA technology helps municipalities of all sizes achieve significant operational, environmental and economic benefits. The system allows integrated, wide-area monitoring and control of all operations – including remote pumping stations, treatment plants, wastewater collection systems, water distribution systems, storm water retention reservoirs, weather monitoring systems, etc. – from a single, centralized location.
Emerson Power & Water Solutions
Pittsburgh, PA
Tel: 800-445-9723
Web: www.emersonprocess.com
Circle No. 246 on Reader Service Card

Nitrate sensor

Hach's NO3D sc Nitrate Sensor provides a new solution for wastewater treatment facilities required to measure nitrate and monitor plant performance. The sensor, with its patented Cartrical™ technology, enables plants to monitor their nitrogen removal online to better understand trends in the treatment process. The nitrate sensor uses an ion-selective electrode (ISE) to detect nitrate ions. It is "plug and play" ready to use with Hach sc Controllers. No complicated wiring or set-up procedures are necessary.
Hach Co.
Loveland, CO
Tel: 800-227-4224
Web: www.hach.com
Circle No. 247 on Reader Service Card

Pump, injection controller

HM Digital's new dual control pump/injection controller (model CIC-152) allows users to monitor and control TDS/EC levels within a specific range. The controller can be wired to activate a device such as a pump, solenoid valve, external light, etc. if the TDS/EC level rises above or falls below the user-defined maximum and minimum. There are also two independent maximum and minimum warning alarm settings independent of the control points.
HM Digital, Inc.
Culver City, CA
Tel: 800-383-2777
Web: www.hmdigital.com
Circle No. 248 on Reader Service Card

Operator's console recorder

Longwatch offers the Operator's Console Recorder, a software module that automatically records images being shown on multiple HMI or SCADA operator's displays. The module takes its signals directly from each HMI screen's video software driver, so it records the actual video being sent to the HMI in a water treatment plant's control room. The software can accommodate video signals from an unlimited number of HMIs to show what operators were watching at the time of an event or alarm.
Longwatch, Inc.
Norwood, MA
Tel: 781-255-7400
Web: www.longwatch.com
Circle No. 249 on Reader Service Card

Propeller flow meter

The Model ML04 Water Specialties Propeller Flow Meter™ from McCrometer is available with an optional transmitter that provides a 4-20 mA output, which indicates either flow rate or totalized flow volume in support of Supervisory Control and Data Acquisition (SCADA) Systems. It is a steel flanged-end tube meter with indicator-totalizer. The meter features measurement accuracy of ±2 percent and measures liquid flow from 40 to 35,000 gpm depending on line size.
McCrometer
Hemet, CA
Tel: 800-220-2279
Web: www.mccrometer.com
Circle No. 250 on Reader Service Card

Well, aquifer level control

OCV's new Well Commander Series provides control of well/aquifer levels to prevent over pumping. The system consists of up to three diaphragm actuated control valves, installed on the discharge of up to three separate wells, and a single, electronic multi-stage controller. The system can be programmed to control up to three process variables per valve, such as pressure, flow and depth. Each valve is independently operated, controlled and monitored.
OCV Control Valves
Tulsa, OK
Tel: 888-628-8258
Web: www.controlvalves.com
Circle No. 251 on Reader Service Card

Remote control

OSI's Remote Information System (OSIRIS) is a secure Remote Terminal Unit designed to meet the needs of the water/wastewater industry. Featuring a modern design based on a 32 bit Linux platform, CANbus interface, and modern I/O ports such as USB and CompactFlash, the system can provide telemetry and control for remote pump stations, tanks, and distributed pipeline networks. Its onboard Web-Enabled secure configuration utility, feature-rich communications interfaces and support for standard protocols such as DNP3, IEC 870-5, and Modbus over both IP and serial connection gives utilities maximum flexibility in deployment.
OSI
Minneapolis, MN
Tel: 763-551-0559
Web: www.osii.com
Circle No. 252 on Reader Service Card

Electromagnetic meter

SeaMetrics offers a miniature electromagnetic flow meter with PVDF wetted components to allow measurement of a wide variety of chemicals. With no moving parts,the PE Meter can handle pulsating flow from diaphragm or peristaltic chemical metering pumps. It is suited for monitoring chemical injection for water treatment.
SeaMetrics Inc.
Kent, WA
Tel: 800-975-8153
Web: www.seametrics.com
Circle No. 253 on Reader Service Card

Water level datalogging

The Solinst Levelogger Gold is a self-contained water level and temperature datalogger. It features 0.05% FS accuracy, 10-year battery and memory for 40,000 sets of readings. It is user-friendly with intuitive software and upgradeable firmware. Infrared data transfer provides the flexibility of direct read or wireline deployment. Lifetime calibration makes the datalogger virtually maintenance free.
Solinst Canada Ltd.
Georgetown, ON Canada
Tel: 905-873-2255 Web: www.solinst.com
Circle No. 254 on Reader Service Card

Process gauge

The Type 43X.50 gauge from WIKA is designed for the process industry and is suitable in corrosive environments for gaseous, liquid or highly viscous media. It has a liquid filled case for applications with high dynamic pressure pulsations or vibration. With all stainless steel construction and high overpressure safety the gauge is suited for multiple industries.
WIKA Instrument Corp.
Lawrenceville, GA
Tel: 678-739-2549
Web: www.wika.com
Circle No. 255 on Reader Service Card

Bluetooth module

WAGO's 750-644 Bluetooth® RF-Transceiver module provides bidirectional, wireless communication between I/O nodes. Within 10ms, the module exchanges data up to1000m open field or 100m (within buildings). This makes the module ideal for SCADA applications, including lift stations and widely dispersed storage. One 750-644 master can communicate with up to seven slaves on a Personal Area Network (PAN), also known as a piconet, via Bluetooth® 2.0+EDR radio technology.
WAGO Corp.
Germantown, WI
Tel: 800-346-7245
Web: www.wago.us
Circle No. 256 on Reader Service Card

Digital pressure gauge

Automation Products Group has introduced the PG7 Digital Pressure Gauge. Specifically engineered for challenging outdoor conditions, the IP67 rated PG7 features a full 5-digit display with large and easily readable 0.4 in. characters that leverages MEMS-based sensing technology for reliability and stability.
Automation Products Group Inc.
Logan, UT
Tel: 888-525-7300
Web: www.apgsensors.com.
Circle No. 257 on Reader Service Card

Remote alarm

For around the clock monitoring, add BobAlert™ cellular remote alarms to a facility for only $15 a month. The wireless system does not require phone or internet lines. It sends alarm notifications by email or text message as soon as your system is in alarm. Operators can receive automatic daily system updates as well as weekly datalog reports. The system can handle up to 4 analog and 5 digital inputs per device. Typical applications include pump and lift stations, tank and well monitoring, chemical inventory management, and cooling/boiler water treatment.
Innovative Waters, LLC
Madison, WI
Tel: 888-455-6641 Web: www.innovativewaters.com
Circle No. 262 on Reader Service Card

Controls, SCADA

Aqua-Aerobic Systems offers design and development of Electrical Control Panels and SCADA systems for wastewater treatment equipment and processes. Its SCADA systems offer a single point of control for plant-wide monitoring, detailed, dynamic graphics depicting equipment status and PLC command status, historical trending and logging of data, consolidated alarming for all SCADA accessed areas, remote access, upgrade capabilities for existing controls, and an optional electronic O&M manual.
Aqua-Aerobic Systems Inc.
Rockford, IL Tel: 815-654-2501 Web: www.aqua-aerobic.com
Circle No. 263 on Reader Service Card

Sodium hypochlorite monitoring

The all new Hypo Trak® Sodium Hypochlorite Monitoring System from Force Flow allows users to track usage, amount remaining, current strength and hypo age remotely from a PLC or SCADA system. In addition, alarms can be sent to indicate a vapor locked metering pump and excessive chlorate formation. The system is housed in a NEMA 4X enclosure and can be used with all Force Flow tank scales and ultrasonic sensors.
Force Flow
Concord, CA
Tel: 800-893-6723
Web: www.forceflow.com
Circle No. 264 on Reader Service Card

Level monitoring

Hawk has introduced the Sultan 234 acoustic wave level transmitters, which can be powered using loop power (2-wire), 3, or 4 wire sources. These instruments emit an acoustic wave pulse, which is then reflected from the surface of the material being measured. The reflected signal is processed using specially developed software to enhance the correct signal and reject false or spurious echoes.
Hawk Measurement
Tel: 888-429-5538
Web: www.hawkmeasure.com
Circle No. 265 on Reader Service Card
