New Products

Fluid Metering has introduced the Chloritro™ valveless metering system for injection of sodium and calcium hypochlorite for purification of municipal drinking water.

Oct 1st, 2009
Pennwell web 200 190

Hypochlorite injection system

Fluid Metering has introduced the Chloritrol™ valveless metering system for injection of sodium and calcium hypochlorite for purification of municipal drinking water. The system uses a unique valveless duplex pump design. The first pump head is high pressure and injects the sodium hypochlorite directly into the water main. The second pump head functions to remove out-gas bubbles from the inlet side of the high-pressure pump head.
Fluid Metering Inc.
Syosset , NY Tel: 800-223-3388 Web: www.chloritrol.com
Circle No. 261 on Reader Service Card

RTU interface

Telog Instruments now provides a MODBUS communications interface for its Ru-33 and RS-33u Recording Telemetry Units (RTU). The new interface makes it possible for the Ru-33 to communicate with a wide range of flow meters, pump station monitors, PLCs and other devices that provide MODBUS protocol interface. Telog RTUs can now "speak" with virtually any metering and control device used in a water distribution or wastewater installation, recording the data collected by these instruments and transferring it directly to the municipality's operations center.
Telog Instruments Inc.
Victor, NY
Tel: 585-742-3000
Web: www.telog.com
Circle No. 263 on Reader Service Card

Circuit breakers

Three 4-channel Electronic Circuit Breakers have joined WAGO Corporatio's 787 Series Power Supply System. The DIN-rail mount 787-860, 787-861 and 787-862 Electronic Circuit Breakers each separately protect up to four current paths (up to 10A at 24 vDC max each), while offering independent programming of appropriate channel- or circuit-specific ratings and trip times via free 759-860 Configuration software. In the event of a fault or short circuit, the circuit breakers can shut down the tripped channel within 100ms. Rather than halting the entire system, power is maintained to other loads (e.g., to a PLC on one path and HMI on another). This prevents a system-wide shut down, as well as possible data loss. Afterward, the tripped load may be remotely reset via a control input.
WAGO Corp.
Germantown, WI
Tel: 800-346-7245
Web: www.wago.us
Circle No. 264 on Reader Service Card

Disinfection systems

Grundfos' Disinfection provides a diverse assortment of products ranging from bleach feed skids and chlorine gas feed to onsite bleach and chlorine dioxide generation. The company's VACCUPERM chlorine disinfection systems measure and control chlorine gas dosing. Its SELCOPERM electrolysis systems generate chlorine directly on site with no critical by-products.
Grundfos Pumps Corp.
Olathe, KS
Tel: 913-227-3400
Web: www.grundfos.us
Circle No. 262 on Reader Service Card

I&I software

MWH Soft has announced the newest release of its RDII Analyst (Rainfall-Derived Inflow and Infiltration) for InfoSWMM and H2OMAP SWMM with expanded functionality. The new version incorporates many advanced features. It also openly invites the users to further adjust the dry weather flow (DWF) and RTK parameters to achieve a better fit – and ultimately a better model – based on their experiences. Enhancements include tabular comparisons between the observed and calibrated RDII data for each event, including R value, peak flow, hydrograph volume and depth.
MWH Soft
Broomfield, CO
Tel: 626-568-6868 Web: www.mwhsoft.com
Circle No. 265 on Reader Service Card

RO pretreatment

Orival Water Filters has been providing automatic filters for RO pre-treatment for over 23 years. Filter sizes range from 20 mm to 600 mm with screen apertures down to 5 microns. Manifold systems can be provided with multiple automatic filters for flexibility and redundancy when flow cannot be interrupted for maintenance or repairs. The water-efficient self-cleaning mechanism does not require filter units to be taken off-line for cleaning. Materials of construction are chosen for the application whether fresh, brackish, sea water or brine.
Orival Inc.
Englewood, NJ Tel: 201-568-3311 Web: www.orival.com
Circle No. 266 on Reader Service Card

Electronic locks

The Videx CyberLock electronic access control system has been incorporated into two new padlocks: the Hockey Puck and the Bar Bell. The electronic Hockey Puck Padlock has a stainless steel body that completely surrounds a stainless steel shackle when closed. Its buried shackle prevents attacks from bolt-cutters. The electronic Bar Bell Padlock has a stainless steel core and locking post. It is environmentally sealed with "O" rings to prevent water and dirt from reaching the inner core of the lock. The unique design of these intelligent padlocks allows them to perform in wet, corrosive environments.
Videx
Corvallis, OR
Tel: 541-758-0521
Web: www.videx.com
Circle No. 267 on Reader Service Card

Grease skimmer

Abanaki has introduced a solution to the problem of unskimmable matted grease in wastewater pits. A new accessory to the company's Grease Grabber® oil skimmer, the MatBuster™ churns the water surface and breaks up matted grease, so the oil skimmer can operate more effectively. The device consists of stainless steel blades that mount to the tail pulley of the Grease Grabber. No separate motor or other moving parts are required.
Abanaki Corp.
Cleveland, OH
Tel: 800-358- 7546
Web: www.abanaki.com
Circle No. 268 on Reader Service Card

Scheduler Module

The Granite XP Scheduler Module from Cues allows users to schedule the transfer of CCTV data and media files and perform database synchronization automatically. At specific times set by the administrator, the CCTV inspection truck(s) can automatically export completed inspections from the truck to the office and synchronize incomplete inspections from the office to the truck to automate the transfer and archival of data on a daily, weekly or monthly schedule. The Scheduler Module can be activated on the Granite XP Inspection Edition, the Engineering Edition, and the Enterprise Edition.
Cues Inc.
Tel: 800-327-7791
Web: www.cuesinc.com
Circle No. 272 on Reader Service Card

Wrench light

A new mini flashlight that clips to the handle of several Lowell ratchet wrenches can help utility and construction workers find and adjust nuts in dark areas. The Hi-Vis Hi-Lite directs light right to the wrench head and work area and frees up both of a worker's hands for working. The light is 3 5⁄8" long, 3⁄4" in diameter, and, with its detachable clip, weighs 1.9 oz.
Lowell Corp.
Tel: 800-456-9355
Web: www.lowellcorp.com.
Circle No. 271 on Reader Service Card

Fire hydrant installation

The Gradelok™ system provides the advantages of a restrained joint and grade adjustment in a single fitting. The system allows utilities to have all fire hydrants set exactly to grade. The system can help expensive extension kits and concrete thrust devices.
Assured Flow Sales Inc.
Tel: 800-388-0678
Web: www.gradelok.com
Circle No. 270 on Reader Service Card

Desalination

Veolia Water Solutions & Technologies has acquired worldwide rights to commercialize a new patented Zero Discharge Desalination (ZDD) technology developed at the University of South Carolina by ZDD Inc. The technology uses a combination of separation processes, including an electrodialysis device in an ion substitution mode to remove divalent salts from water.
Veolia Water Solutions & Technologies
Houston, TX
Tel: 412-809-6712
Web: www.veoliawater.com
Circle No. 269 on Reader Service Card

Flushing system

The Hydro-Guard® S.M.A.R.T. flushing system will allow for two way communication and remote flushing unit management via either a secure web portal or a secure interface with the client's existing SCADA. The system can be integrated with a residual analyzer and a variety of other water quality management devices. This integration will allow the system to flush when the disinfectant residual drops below the parameters established by the end-user as opposed to flushing on a time-based schedule.
Hydro-Guard®
Naples, FL
Tel: 877-864-8500
Web: www.hydro-guard.com
Circle No. 273 on Reader Service Card
