Batteries inspire next generation of desalination research

A battery inspired water distillation process could be more efficient and hold several advantages compared to traditional reverse osmosis desalination, researchers have claimed...

Content Dam Ww Online Articles 2016 02 Batteries 1419437 640x480

Content Dam Ww Online Articles 2016 02 Batteries 1419437 640x480

CHAMPAIGN, Ill. – A battery inspired water distillation process could be more efficient and hold several advantages compared to traditional reverse osmosis (RO) desalination, researchers have claimed.

The University of Illinois mechanical science and engineering professor Kyle Smith and graduate student Rylan Dmello published their work in the Journal of the Electrochemical Society.

Researchers were inspired by sodium ion batteries, which contain salt water. Batteries have two chambers, a positive electrode and a negative electrode, with a separator in between that the ions can flow across.

When the battery discharges, the sodium and chloride ions - the two elements of salt - are drawn to one chamber, leaving desalinated water in the other.

In a normal battery, the ions diffuse back when the current flows the other direction. The Illinois researchers looked to find a way to keep the salt out of the now-pure water.

The battery method uses electricity to draw charged salt ions out of the water.

Desalination Uni Illinois

According to the researchers, the method could hold several advantages over RO membrane processes.

The battery device can be small or large, adapting to different applications, while reverse osmosis plants must be very large to be efficient and cost effective, Smith said.

The pressure required to pump the water through is much less, since it's simply flowing the water over the electrodes instead of forcing it through a membrane. This translates to much smaller energy needs, close to the very minimum required by nature, which in turn translates to lower costs.

Smith and Dmello conducted a modeling study to see how their device might perform with salt concentrations as high as seawater, and found that it could recover an estimated 80% of desalinated water. Their simulations don't account for other contaminants in the water, however, so they are working toward running experiments with real seawater.

In addition, the rate of water flowing through it can be adjusted more easily than other types of desalination technologies that require more complex plumbing, the university said.

Smith said: "In a conventional battery, the separator allows salt to diffuse from the positive electrode into the negative electrode. That limits how much salt depletion can occur. We put a membrane that blocks sodium between the two electrodes, so we could keep it out of the side that's desalinated."

###
