Products & Services: Pipe

Pipe supports by Reliner® are fully adjustable clamping pipe brackets made of non-corrosive 11 gauge 304 stainless.

Pennwell web 210 161

Pipe supports

Pennwell web 210 161

Pipe supports by Reliner® are fully adjustable clamping pipe brackets made of non-corrosive 11 gauge 304 stainless. They securely attach pipes to manhole walls and other surfaces with no protruding hardware and are adjustable to fit irregular surfaces. They are often used with the company's Inside Drop Bowl to eliminate outside drops in sanitary sewers or stormwater drops. The clamps attach to the structure wall with 3⁄8" stainless steel bolts in non-corrosive shields.
Reliner®/ Duran Inc.
Lyme, CT
Tel: 800-508-6001
Web: www.reliner.com
Circle No. 209 on Reader Service Card

CCTV rig

Pennwell web 210 158

CUES has introduced the self-contained K2 Wireless Base Station portable CCTV inspection system. The system is mounted in a compact, lightweight, weatherproof enclosure that can fit into an ATV, van, trailer, or pick-up truck to access easements and hard-to-reach areas. A hand-held portable wireless control is supplied that operates all CUES zoom/pan and tilt cameras, transporters and reels for 4"-200" pipe inspection.
CUES Inc.
Tel: 800-327-7791
Web: www.cuesinc.com
Circle No. 210 on Reader Service Card

Sewer liner

Pennwell web 210 165

The T-Hab™ system from Ameron Protective Linings Division is a trenchless, large diameter sewer tunnel and pipeline rehabilitation process that uses the T-Lock PVC liner technology. The system can be used to rehabilitate either cylindrical or non-cylindrical tunnel and pipe configurations. T-Lock sheets are pre-manufactured to the required circumferential dimension and applied using a quick-curing, structural grout.
Ameron Protective Linings Division
Tel: 936-321-1159
Web: www.amerontlock.com
Circle No. 211 on Reader Service Card

Plastic pipe guide

It is now easier to design and write high-density polyethylene pipe (HDPE) into a specification or respond to an RFP for a buried potable water system by using a new guide developed by the Plastics Pipe Institute. Issued in December 2009, Model Specification MS-3/2009 provides design engineers, public works directors, and others, including city officials, with an easy to follow template that includes authoritative references that can be included in a design, an RFP, or other documentation for a project.
Plastics Pipe Institute Inc.
Irving, TX
Circle No. 212 on Reader Service Card

Centrifugally cast pipe

Pennwell web 210 137

After more than 25 years of service, HOBAS pipe has been used in new construction and rehab in critical installations including storm and sanitary sewers, potable water and corrosive environments. It is suited for variety of installation methods including open cut, sliplining, jacking, microtunneling, two-pass tunnel, casing carrier and above ground.
Hobas Pipe USA
Houston, TX Tel: 800-856-7473 Web: www.hobas.com
Circle No. 213 on Reader Service Card

Pipe products

Pennwell web 210 158

Underground Solutions provides infrastructure technologies for water and wastewater applications. Its PVC products, including Fusible C-900®, Fusible C-905® and FPVC®, contain a proprietary PVC formulation that, when combined with UGSI's patented fusion process, results in a monolithic, fully-restrained, gasket-free, leak-free piping system ideal for numerous trenchless or conventional "open-cut" applications including horizontal directional drill (HDD), pipe bursting, sliplining and open trench.
Underground Solutions Inc.
Cranberry Township, PA Tel: 724-353-3000 Web: www.undergroundsolutions.com
Circle No. 214 on Reader Service Card

Pipe inspection system

Pennwell web 210 222

The PipeDiver™ pipeline inspection system has been specifically designed to operate in live pipelines, guaranteeing uptime and avoiding costly dewatering and service shutdown. This free-swimming tool travels long distances and collects critical data about the structural integrity of the pipeline, identifying pipe sections that are at risk of failure.
Pressure Pipe Inspection Co.
Mississauga, ON
Tel: 877-275-7742
Web: www.ppic.com
Circle No. 216 on Reader Service Card

Joint restraints

Pennwell web 210 193

Smith-Blair has announced the addition of the Pipe-Lock to its Joint Restraint product line. The fabricated steel sleeve restraint coupling can be used to connect and restrain plain end pipe to plain end pipe. Its restrained joint requires no other method of restraining the pipe. It is available in straight, transition and reducing couplings in sizes 3"-36" for PVC and 3"-48" for ductile iron.
Smith-Blair
Texarkana, AR
Tel: 800-643-9705
Web: www.smith-blair.com
Circle No. 215 on Reader Service Card

Lateral inspection camera

Pennwell web 210 207

The RIDGID® the SeeSnake microReel L100 and L100C inspection system is a complete compact, portable drain inspection system for users needing to push cable distances of up to 100 feet in lines from 1½" to 4" in diameter. Designed for use in lateral lines that exit the building and connect to septic or sewer lines, as well as in roof stacks, the inspection system features a 100-foot cable and a 25-mm camera head.
RIDGID®
Elyria, OH
Tel: 800-769-7743
Web: www.ridgid.com
Circle No. 217 on Reader Service Card

Custom steel pipe

Pennwell web 210 284

Pipe solutions customized to suit each project's requirements are available with Northwest Pipe Company' Performance-Based Design. The company's engineered steel pipe can save money on materials and time on the jobsite. Its pipe products offer high strength with low weight and a flexible design that features bottle-tight joints that don't require perfect trench conditions to maintain their watertight integrity.
Northwest Pipe Co.
Vancouver, WA
Tel: 800-989-9631
Web: www.nwpipe.com
Circle No. 218 on Reader Service Card

PVC sewer pipe

Pennwell web 210 191

CertainTeed has expanded its CertaFlo™ GreenLine PVC Sewer Pipe line to include larger pipe diameters. The pipe is now available in diameters ranging from 4" to 12". The high-impact polyvinyl chloride (PVC) pipe features the company's Certa-Lok™ Integral Bell restrained joint system. It is available in 10- and 20-foot lengths for ease of use in trenchless applications, such as directional drilling and pipebursting. The shorter lengths facilitate rapid assembly and allow the use of smaller and more economical construction pit sizes.
CertainTeed Corp.
Valley Forge, PA
Tel: 866-284-7473
Web: www.certainteed.com
Circle No. 219 on Reader Service Card

Pipe bursting

Pennwell web 210 133

Utilities can burst and replace water and sewer pipes with the Grundoburst static pipe bursting system from TT Technologies. The Grundoburst can pull in a variety of replacement pipe including PVC, DIP, ABS, cast iron, fusion welded HDPE and VCP jacking pipe. Pulled by a hydraulic bursting unit, the cutter head's special cutting wheels split the host pipe. Six models are available for bursting 2" through 54" pipes and larger.
TT Technologies
Aurora, IL
Tel: 630-851-8200 Web: www.tttechnologies.com
Circle No. 220 on Reader Service Card

Vacuum lifting system

Pennwell web 210 210

The new MC3 "Mini" Lifter from Vacuworx has a 6,600 lb lifting capacity. The self-contained lifter attaches to normal size host machines, as well as mini excavators, skid steer loaders, backhoes, and others. It has a dry weight of 900 lbs. It can be used to lift and move steel plate, concrete slab, landscape rock, steel and poly pipe, and many other types of material.
Vacuworx International
Tel: 866-664-3450
Web: www.vacuworx.com
Circle No. 221 on Reader Service Card

Fiberglass reinforced pipe

Flowtite® fiberglass reinforced pressure pipe offers a smooth internal surface with improved hydraulic characteristics. The filament wound fibers used in the continuous advancing manufacturing process provide a true pressure pipe design with superior hoop strength. This process also allows the production of custom length pipe to reduce transportation and installation costs. The pipe is available in diameters up to 156", and pressure ranges up to 250 psi (higher pressures in certain diameters). The pipe is not affected by UV exposure and demonstrates minimal thermal expansion/contraction. It is suitable for below and above ground installation.
U.S. Composite Pipe South, LLC
Zachary, LA
Tel: 225-658-6166
Web: www.uscpsouth.com
Circle No. 222 on Reader Service Card

Pipe mapping system

The Smart Probe™ from Geospatial Corp. is an autonomous mapping system that can determine, in 3D, the location of any utility pipe with internal diameters ranging from 1.5" to 60". Traveling through a pipeline at up to six feet per second, the probe records 800 angular and linear velocity changes per second along the x, y and z axes. The data acquired by the probe can be stored on a PC or viewed and evaluated in the field, or can be transferred via the Internet for evaluation by anyone, or stored and entered into a GIS/CAD database for future reference.
Geospatial Corp.
Tel: 724-353-3400
Web: www.geospatialcorporation.com
Circle No. 223 on Reader Service Card
