Product Showcase

Emerson's Ovation® Security Center helps water and wastewater facilities tackle mounting pressure to enhance their cyber-security initiatives as part of their overall efforts to safeguard public health and the environment.

Pennwell web 200 265

Cyber security

Pennwell web 200 265

Emerson's Ovation® Security Center helps water and wastewater facilities tackle mounting pressure to enhance their cyber-security initiatives as part of their overall efforts to safeguard public health and the environment. Tightly integrated with the company's Ovation expert control system, the system streamlines and centralizes execution of cyber-security management functions, enabling water and wastewater facilities to more easily manage security efforts. The centrally located console streamlines management of numerous security applications including security event management; patch deployment and audit; malware prevention; event log storage and reporting; and vulnerability assessment and management.
Emerson Power & Water Solutions
Pittsburgh, PA Tel: 800-445-9723 Web:
Circle No. 200 on Reader Service Card

Portable DO monitoring

Pennwell web 200 270

Extech Instruments has released the Model DO700 Portable Dissolved Oxygen meter. Part of the company's Waterproof Series of products, the device is a 9-in-1 meter designed for both lab and demanding field applications, including wastewater and environmental monitoring. It measures DO concentration/saturation, pH, mV, conductivity, TDS, salinity, resistivity and temperature. It also features automatic salinity compensation and manual barometric pressure compensation for DO measurements. The meter comes equipped with a three point pH calibration for better accuracy, automatic temperature compensation and a one point conductivity calibration. The DO700's memory stores up to 400 readings with series number, measured value and temperature.
Extech Instruments
Waltham, MA
Tel: 781-890-7440
Circle No. 201 on Reader Service Card

Portable turbidimeter

Pennwell web 200 145

The 2100Q Portable Turbidimeter offers a combination of advanced features, such as on-screen assisted calibration and verification, simplified data transfer, and improved measurement for rapidly settling samples. The easy-to-follow interface eliminates the need for complicated manuals to perform routine calibrations and verification, and the single-standard RapidCal™ calibration offers a simplified solution for low level measurements. Data logging stores up to 500 measurements in the instrument and customizable power and connectivity modules offer flexibility in data transfer.
Hach Co.
Loveland, CO Tel: 800-227-4224 Web:
Circle No. 203 on Reader Service Card

Check valves

Pennwell web 200 153

The TF-1 Curved Bill Tideflex® Check Valve prevents floodwater from surcharging sewer lines and washing raw sewage into streets and basements. During flood events, the valve prevents floodwater from backflowing into sewage treatment plants. The check valve was specifically designed for sewer system installations. Its curved bill enhances sealing, requires less bottom clearance and can hold greater water weight than the original Tideflex® Check Valve designed in 1984. The valve is constructed entirely of rubber, making it immune to rust, corrosion and weathering. The curved bill offers increased flexibility to better seal around entrapped debris, and the headloss of the valve remains exceptionally low. Sizes are available to 96".
Tideflex Technologies
Carnegie, PA
Tel: 412-279-0044
Circle No. 202 on Reader Service Card

Blowers, exhausters

Pennwell web 200 220

The TurboTron® Regenerative Full Flow and Half Flow blowers/exhausters from Gardner Denver are specifically designed to provide continuous flow and pulse-free air suitable for wastewater treatment aeration systems. The regenerative blowers are packaged in various pre-engineered "TurboPak" systems and are available as belt drive, direct drive, overhung and even VFD configurations. The Full Flow series offers airflow to 900 cfm and pressure to 13 psig. The Half Flow series offers airflow to 450 cfm and pressure to 13 psig.
Gardner Denver Inc.
Quincy, IL
Tel: 800-232-0865
Circle No. 204 on Reader Service Card


Pennwell web 200 247

The NIRQuest Spectrometer from Ocean Optics is used for environmental monitoring and contaminant detection in wastewater and soil. The compact, multi-interface spectrometer is available in versions for coverage from 900-1700 nm, 900-2050 nm and 900-2500 nm. It provides a less costly alternative to FT-IR and comparable technologies currently used in environmental monitoring. The device has a modular design and uses an Indium Gallium Arsenide (InGaAs)-array detector in a compact optical bench, thermoelectric cooler and low-noise electronics. A high gain mode option improves system sensitivity for low light-level and low-concentration measurements.
Ocean Optics
Dunedin, FL
Tel: 727-733-2447 Web:
Circle No. 206 on Reader Service Card

Sealing system

Pennwell web 200 133

Pipeline Seal & Insulator has introduced the new Boa-Tape™ infiltration sealing tape. Requiring no torch and no primer, the pressure sensitive woven polypropylene tape seals concrete, steel and polyethylene structures. Designed to seal joints against ground water infiltration, the 50 mil elastomeric adhesive in combination with 15 mils of a woven polypropylene makes this tape extra sticky for extra grip. For re-hab, where grout has failed, and new construction, the tape sealing system can also be applied to pipe structures to control corrosion.
Pipeline Seal & Insulator Inc.
Houston, TX
Tel: 800-423-2410
Circle No. 207 on Reader Service Card

Tank monitoring

Pennwell web 200 275

Nitz Associates' TankMeter 1000 Series determines pre-charge pressure, liquid volume and gas pressure inside any tank. The meter has a hand-held Wireless Remote Display that automatically synchronizes tank information up to a range of 200 feet. It holds more than 1000 readings per tank and stores data on over 200 tanks simultaneously. TankSoft software is ideal for archiving readings and plotting trend lines.
Nitz Associates Inc.
Camarillo, CA
Tel: 805-484-1485
Circle No. 205 on Reader Service Card
